DFP 01 37264-4-0369562 ABB Bailey Analog Input Module
Brand：ABB Model number：DFP 01 37264-4-0369562
Country of origin: Sweden Product weight：0.55KG
HS code：8517623990
Product Details：
Product Dimensions：
The DFP 01 module acts as a critical power interface within the ABB Bailey architecture. It is specifically engineered to support the HNET (Harmony Network) and is often utilized to power Bridge Controllers or field-mounted interface units. The module is designed for rack or DIN-rail mounting depending on the specific chassis configuration, featuring a robust physical build that protects internal electronics from the vibration and electrical noise common in industrial settings. It converts standard AC utility power into the precise DC voltages required by the sensitive logic circuits of the Bailey controllers.
Product Type: Field Controller Power Supply Module
Input Voltage: $100\text{--}240\text{ VAC}$ (nominal), $50/60\text{ Hz}$
Output Voltage: $24\text{ VDC}$ (regulated)
Maximum Output Power: $60\text{ W}$
Maximum Output Current: $2.5\text{ A}$
Efficiency: $\geq 85\%$
Operating Temperature: $-20^\circ\text{C}$ to $60^\circ\text{C}$ ($-4^\circ\text{F}$ to $140^\circ\text{F}$)
Storage Temperature: $-40^\circ\text{C}$ to $85^\circ\text{C}$
Protection Rating: IP20 (intended for installation in protective cabinets)
Approximate Weight: $0.5\text{ kg}$ ($1.1\text{ lbs}$)
Dimensions: Approximately $12.7 \times 7.6 \times 17.8\text{ cm}$
High Reliability: Engineered for continuous $24/7$ operation, the DFP 01 ensures that the control system remains online even under fluctuating power conditions.
Integrated Protection: The module features built-in overload and short-circuit protection, preventing downstream damage to expensive controller modules in the event of a field wiring fault.
Seamless Compatibility: As an authentic Bailey Controls component, it offers "plug-and-play" integration with the Symphony Harmony system, eliminating the need for custom mounting or voltage regulation equipment.
Efficient Heat Dissipation: The design prioritizes thermal management, allowing the unit to maintain full power output across a wide temperature range without requiring external cooling fans.
Installation Environment: Because the module is rated IP20, it must be installed in a clean, dry, and dust-free enclosure. Exposure to moisture or corrosive gases can lead to premature failure.
Ventilation Space: When mounting the module, ensure adequate clearance around the unit to allow for natural convection cooling; overcrowding the rack can lead to thermal shutdown.
Electrical Safety: Always verify that the input voltage matches the module's specifications before applying power. Ensure the system is properly grounded to mitigate electromagnetic interference (EMI).
Obsolescence Management: As the Bailey Harmony series is a legacy system, users should maintain spare DFP 01 units, as lead times for original parts may be longer than current-generation hardware.
The DFP 01 module is widely deployed in heavy industries where the ABB Bailey system is the standard for process automation.
Power Generation: Providing power to controllers in coal, gas, or nuclear power plants to manage boiler controls and turbine operations.
Chemical and Petrochemical: Supporting field controllers that monitor pressure, temperature, and flow in hazardous processing areas.
Water and Wastewater: Ensuring reliable power for sensors and actuators in treatment facilities and pumping stations.
Metals and Mining: Used in the automation of blast furnaces and mineral processing equipment where high vibration and high temperatures are present.
