AN-X4-AB-DHRIO PROSOFT

Product Dimensions：

Parameters for ProSoft Gate Modules vary by model and intended application, but key specifications generally include:

• Supported Protocols: The primary function is to bridge protocols. Examples include EtherNet/IP, Modbus TCP/IP, Modbus Serial, PROFIBUS, PROFINET, DNP3, and legacy protocols like DH+.

• Voltage: Most modules operate on a standard industrial DC power supply, typically 24 VDC nominal, with an allowed range from 10 to 36 VDC.

• Data Transfer Rate: Ethernet-based modules typically support 10/100 Mbps communication. Serial ports may have configurable baud rates.

• Data Capacity: The amount of data the module can store and transfer, often measured in registers or bytes (e.g., up to 10,000 16-bit registers, 1440 bytes of input/output data).

• Ports: The number and type of communication ports, such as RJ45 for Ethernet, and RS-232, RS-485, or RS-422 screw terminals for serial communication.

• Environmental Ratings: Industrial-grade operating temperature ranges, often from -25°C to 70°C, and a high tolerance for shock and vibration (e.g., 5G vibration, 15G shock).

• Physical Characteristics: Typically compact, DIN-rail mountable for easy installation in control cabinets. Dimensions are module-specific.

Product Advantages

• Seamless Protocol Conversion: The primary advantage is the ability to connect incompatible devices and networks, eliminating the need to replace existing equipment.

• Simplified Integration: ProSoft gateways are often provided with tools and Add-On Profiles (AOPs) for simple integration with popular PLC software, reducing commissioning time.

• Robust and Reliable: Built to withstand harsh industrial environments, ensuring reliable and continuous operation in demanding applications.

• Bi-directional Data Transfer: Most modules allow for high-speed, bi-directional data exchange, enabling both control and data acquisition across networks.

• Enhanced Diagnostics: Integrated diagnostic features and status LEDs help users quickly monitor network health and troubleshoot communication issues.

• Disaster Recovery: Many modules include a SD card slot for storing configuration files, allowing for quick recovery and simplified module replacement.

Important Considerations

• Protocol Compatibility: Carefully select a gateway that supports all the specific protocols and versions you need to bridge.

• Data Mapping: Proper configuration and mapping of data between the source and destination devices is crucial. This often requires understanding the register addresses and data types of each protocol.

• Firmware and Software: Ensure you have the correct and up-to-date firmware and configuration software (like ProSoft Configuration Builder) for your specific module.

• Network Performance: While gateways enable communication, they can introduce a small amount of latency. Consider the required data update rates (RPIs) and bandwidth of your application.

• Physical Installation: Follow proper grounding and shielding practices for wiring, especially for serial communication, to prevent electrical noise and ensure data integrity.

Product Applications

ProSoft Gate Modules are widely used across various industries for critical communication and integration tasks:

• Factory Automation: Connecting new EtherNet/IP-based PLCs to legacy Modbus RTU devices like power meters or temperature controllers.

• Process Control: Integrating various field devices on different networks (e.g., a PROFIBUS PA network of instruments to a central control system on EtherNet/IP).

• Building Automation: Bridging building management systems (BMS) with industrial control networks for unified control and monitoring of HVAC and security.

• Oil & Gas: Enabling communication between remote terminal units (RTUs) on a Modbus serial network and a central SCADA system on a corporate Ethernet network.

• Water/Wastewater: Integrating PLCs with remote telemetry units (RTUs) for pump and valve control over various protocols.

• Machine-to-Machine (M2M) Communication: Enabling different machines or subsystems, each with a different communication protocol, to share data and coordinate actions.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！

PROSOFT ILX56-MM

PROSOFT PLX32-EIP-MBTCP-UA

PROSOFT MV156-PDPMV1

PROSOFT PLX51-PBM

PROSOFT PLX32-EIP-PND

PROSOFT PLX51-HART-4I

PROSOFT PLX51-DF1-ENI

PROSOFT MV156E-MNETR

PROSOFT ILX56-PBM

PROSOFT AN-X4-AB-DHRIO

Colour：new                                   Warranty: 12 months

Lead Time：3-day working day      Price: Please contact us

Shipping Port: Xiamen, China         Payment:T/T

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
