INRAX-MVI94-MCM PROSOFT

Product Dimensions：

ProSoft Technology, a brand now part of Belden, specializes in industrial communication and connectivity solutions. Their "circuit boards" are typically highly specialized communication modules designed to be integrated directly into a PLC (Programmable Logic Controller) or other control system backplanes. These are not generic circuit boards but purpose-built modules that enable a PLC to communicate with a wide range of devices and networks that it otherwise couldn't. These modules effectively function as gateways or bridges, allowing disparate equipment to share information.

• Functionality: ProSoft's circuit boards are the physical hardware for their communication modules, which perform protocol conversions. For example, a module might allow a Rockwell Automation ControlLogix processor to communicate with devices using the Modbus TCP/IP protocol. They manage the complex data exchange, message formatting, and timing required for different industrial networks, offloading this processing from the main PLC.

• Types: ProSoft offers a vast array of these modules, often categorized by the platform they plug into and the protocol they support. Common types include:

• In-Chassis Modules (e.g., inRAx series): These modules slide directly into a PLC rack (like Rockwell Automation's ControlLogix, CompactLogix, or SLC platforms). They draw power from the backplane and communicate with the processor over the backplane bus.

• Standalone Gateways (e.g., ProLinx series): These are self-contained devices with their own power supply and enclosure, used for protocol conversion between different networks or devices.

• Wireless Modules: These modules enable wireless communication between controllers, often used for mobile equipment or remote monitoring.

• Key Features:

• Protocol Conversion: The core function, allowing communication between incompatible devices (e.g., EtherNet/IP to Modbus, PROFIBUS to DH+).

• High-Speed Processing: Dedicated processors on the module handle communication tasks, freeing up the main PLC for core control logic.

• Diagnostic Tools: Many modules include on-board displays (e.g., 4-character LED), status indicators, and embedded web servers for configuration and troubleshooting.

• Robust Design: Built to withstand industrial environments with features like conformal coating for protection against dust, moisture, and corrosive elements.

Product Parameters

Given the wide variety of modules, parameters are specific to each product. However, general parameters include:

• Supported Protocols: The specific industrial protocols the module can communicate with (e.g., Modbus TCP/IP, PROFIBUS DP, PROFINET, DH+, BACnet).

• Backplane Current Load: The electrical draw from the PLC chassis (e.g., 800 mA at 5 VDC).

• Operating Voltage: The required power supply for standalone gateways (e.g., 24 VDC).

• Operating Temperature: The environmental temperature range the module can tolerate (e.g., -25°C to 70°C for XT "eXtreme Temperature" models).

• Communication Ports: Physical connections on the module (e.g., RJ45 Ethernet, RS-232, RS-485, screw terminals).

• Data Memory: The amount of data the module can hold for mapping between the PLC and the external network (e.g., up to 10,000 16-bit registers).

• Certifications: Compliance with standards like UL, CE, and specific hazardous location ratings.

Product Advantages

• Seamless Integration: Modules are designed to integrate seamlessly into a PLC's programming environment (e.g., RSLogix 5000, Studio 5000), often with pre-built Add-On Instructions (AOIs) that simplify configuration.

• Offloading Work: By handling complex communication protocols, these modules reduce the processing load on the main PLC, improving the overall performance and scan time of the control system.

• Extended Connectivity: They enable a control platform to connect with legacy or non-standard devices, extending the life of existing equipment and avoiding costly rip-and-replace projects.

• Enhanced Diagnostics: The on-board diagnostics and web servers provide powerful troubleshooting tools, helping maintenance staff quickly pinpoint and resolve communication issues.

• Robustness: Their industrial-hardened design ensures reliable operation in demanding and harsh environments.

Important Considerations

• Platform Compatibility: Always ensure the ProSoft module is compatible with the specific PLC platform and firmware version you are using.

• Protocol Selection: Correctly identify the communication protocols of all devices to ensure the chosen module can bridge them effectively.

• Configuration Software: ProSoft provides its own configuration tools, such as the ProSoft Configuration Builder (PCB). You must use the correct version of this software to configure and manage the module.

• Network Design: For industrial networks, proper network design, including IP addressing, network topology, and security, is crucial for reliable communication.

• Legacy Systems: When modernizing or expanding legacy systems, carefully plan the migration and ensure the new communication module is properly integrated without disrupting existing processes.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！
