UDI1700 HONEYWELL Analog Input Module
Brand：HONEYWELL Model number：UDI1700
Country of origin: United States Product weight：0.4kg
HS code：8517623990
Product Details：
Product Dimensions：
The UDI1700 is a microprocessor-based instrument that accepts a wide range of input types, making it a "universal" solution for various sensing needs. It features a high-visibility, 4-digit LED display that can be configured to show the process variable in various units. The device is housed in a rugged plastic case designed for panel mounting. It includes a user-friendly front keypad for configuration and can be equipped with up to three output relays for alarm signaling or basic process control. Its compact size and flexible input architecture make it a standard choice for both original equipment manufacturers (OEMs) and end-users in factory automation.
Input Types: Universal input supporting Thermocouples (J, K, R, S, T, L, B, N), RTDs (PT100), and Linear DC ranges (0-20mA, 4-20mA, 0-5V, 1-5V, 0-10V, 2-10V).
Accuracy: Typically $\pm 0.1\%$ of input span $\pm 1$ LSD (Least Significant Digit).
Sample Rate: 4 samples per second.
Display: 4-digit LED, $13 \text{ mm}$ (0.53 inch) high, available in red or green.
Power Supply: $100-240 \text{ VAC}$ ($50/60 \text{ Hz}$) or optional $24-48 \text{ VAC/VDC}$.
Output Options: Up to 3 plug-in outputs (Relay, SSR Driver, or Triac) for alarms or retransmission.
Communication: Optional RS-485 Modbus RTU support for integration into SCADA systems.
Panel Protection: IP66 / NEMA 4X rated front face when properly installed with the supplied gasket.
Dimensions: 1/8 DIN ($96 \text{ mm} \times 48 \text{ mm}$ front face).
A primary advantage of the UDI1700 is its Universal Input Versatility. By supporting almost all standard industrial sensors, a single unit can be kept as a spare for multiple different measurement points, reducing inventory costs. The High Visibility Display ensures that operators can quickly check process status from a distance, even in poorly lit industrial environments.
The Modular Output Design allows for easy field upgrades; users can plug in different output boards (such as adding a third alarm relay or a 4-20mA retransmission board) as application needs evolve. Additionally, its Simplified Configuration menu enables technicians to set up the device in minutes without requiring complex programming software or specialized training.
When installing the UDI1700, ensure the Panel Cutout is exactly $45 \text{ mm} \times 92 \text{ mm}$ to maintain the IP66 environmental seal. Electrical Noise Isolation is critical; signal input wires (like thermocouples) should be kept separate from high-power AC lines to prevent measurement fluctuations.
It is vital to verify the Power Supply Voltage before energizing the unit, as applying $240 \text{ VAC}$ to a $24 \text{ V}$ model will cause terminal damage. When using the unit for Safety Alarms, ensure the relays are configured in a "fail-safe" mode where the relay de-energizes upon an alarm condition or power failure. Lastly, always use Shielded Cables for analog inputs and ground the shield at one end only to avoid ground loops that can introduce measurement offset.
The Honeywell UDI1700 is utilized across a broad spectrum of industries where local visualization of data is required.
Heat Treatment: Monitoring furnace temperatures and providing over-temperature alarm signals to independent safety systems.
Food and Beverage: Displaying storage tank levels or pasteurization temperatures to ensure food safety compliance.
Plastic Extrusion: Monitoring melt pressure and temperature at the extruder die to maintain product quality.
Water Treatment: Visualizing flow rates and pH levels in localized chemical dosing stations.
Laboratory Equipment: Integrated into test benches and environmental chambers for precise monitoring of experimental conditions.
