SLG720 HONEYWELL

Product Dimensions：

The SLG720 operates on the principle of Time Domain Reflectometry (TDR). The transmitter sends a low-energy microwave pulse down a probe (the guide). When the pulse reaches the surface of the liquid, a portion of the energy is reflected back to the electronics. The device measures the time-of-flight to determine the distance to the product surface. Because the pulse is physically guided by a probe, the signal is much more focused and less susceptible to interference from tank internals or foam compared to non-contact radar systems. It features a modular design with a standard alphanumeric display and high-pressure/high-temperature capabilities.

Product Parameters

• Measurement Range: Supports probe lengths up to $50 \text{ meters}$ ($164 \text{ feet}$) depending on the probe type (coaxial, rigid, or flexible cable).

• Accuracy: Standard accuracy of $\pm 3 \text{ mm}$ or $0.03\%$ of the measured distance.

• Process Pressure: Capable of operating in vacuum up to $400 \text{ bar}$ ($5800 \text{ psi}$).

• Process Temperature: Standard models range from $-60\text{°C}$ to $450\text{°C}$ ($-76\text{°F}$ to $842\text{°F}$).

• Output Signal: 4-20 mA DC with HART, Foundation Fieldbus, or Honeywell Digitally Enhanced (DE) protocols.

• Dielectric Constant: Can measure liquids with a dielectric constant as low as $1.4$.

• Enclosure Rating: NEMA 4X and IP66/67 explosion-proof housing.

• Safety Integrity Level: SIL 2/3 certified for use in safety-instrumented systems.

Product Advantages

One of the primary advantages of the SLG720 is its Immunity to Process Fluctuations. Unlike hydrostatic or ultrasonic sensors, the GWR technology is not affected by changes in pressure, vacuum, or vapor space composition. The Modular Hardware design allows for the replacement of the display or electronic modules in the field without breaking the pressure seal of the vessel.

The Advanced Diagnostics suite provides real-time information about the signal quality and probe buildup, which reduces the need for manual inspections. Furthermore, the Dual Interface Measurement capability allows the SLG720 to measure both the total level and the interface between two liquids (such as oil and water) simultaneously, providing high value in separation processes.

Important Considerations and Precautions

When installing the SLG720, the No-Fly Zone or clearance around the probe must be respected; if the probe is installed too close to a metal wall or agitator, "ghost echoes" may occur, leading to false readings. For Coaxial Probes, ensure the liquid is clean, as slurries or viscous liquids can clog the space between the inner and outer rods.

It is also vital to check the Compatibility of the Probe Material (typically 316 Stainless Steel or Hastelloy) with the chemical properties of the process medium to prevent corrosion. During commissioning, users should perform a Background Subtraction (mapping) to tell the device to ignore static reflections from internal tank structures. Finally, ensure that the Cable Tension on flexible probes is maintained if a weight is used, as a slack cable can lead to measurement errors or mechanical damage to the probe.

Product Applications

The Honeywell SLG720 is utilized across heavy industries where precision level monitoring is safety-critical.

• Oil and Gas: Monitoring separators and storage tanks where oil-water interfaces must be managed accurately.

• Chemical Industry: Level measurement in distillation columns and reactors under high-pressure and high-temperature conditions.

• Power Generation: Monitoring feedwater heaters and boiler drum levels where steam and high temperatures typically interfere with other technologies.

• Pulp and Paper: Controlling levels in storage vats and chemical recovery tanks.

• Mining and Minerals: Measuring levels in thickener tanks and slurry mixers where dust or vapor is present.
