AWT200048 ABB Bailey

Product Dimensions：

The AWT200048 acts as a core processing or functional module within ABB's modular transmitter architecture. Designed to slide or mount directly into the main analyzer housing, this module handles low-level analog signals from specialized analytical sensors and converts them into stabilized digital data or standardized industrial outputs. It incorporates advanced filtering circuitry to isolate field sensor signals from industrial electromagnetic noise, ensuring that the analyzer's CPU receives highly accurate, real-time measurements. The component is built with industrial-grade semiconductor parts to guarantee a long operating life under continuous, 24/7 process cycles.

Product Parameters

• Product Type: Analytical transmitter electronic module / processing board.

• Compatibility: Specifically engineered for ABB AWT-series modular liquid analyzers.

• Power Supply: Typically powered internally by the analyzer's backplane or a dedicated $24 \text{ VDC}$ line.

• Input Signal Support: Optimized for low-current and high-impedance analytical sensor signals.

• Operating Temperature Range: Rated for industrial cabinet or housing environments, generally operating from $-20\text{°C}$ to $60\text{°C}$ ($-4\text{°F}$ to $140\text{°F}$).

• Storage Temperature: $-40\text{°C}$ to $70\text{°C}$ ($-40\text{°F}$ to $158\text{°F}$).

• Relative Humidity Compatibility: Up to 95% non-condensing when sealed within the primary transmitter enclosure.

• Circuit Isolation: Features galvanic isolation up to $500 \text{ V}$ to prevent ground loop interference from affecting measurement accuracy.

Product Advantages

A major benefit of the AWT200048 is its Modular Plug-and-Play Design. This architecture allows maintenance technicians to replace or upgrade the internal electronics of the transmitter quickly without having to pull out field wiring or scrap the entire analyzer housing. The High Noise Immunity of the onboard signal conditioning circuitry ensures that precise analytical measurements can be taken even when the unit is placed near high-power variable frequency drives (VFDs) or heavy motors.

Additionally, its Robust Self-Diagnostics capability allows the module to continuously monitor its own internal voltage levels and hardware health, flagging errors instantly to the master controller before bad data can corrupt a process loop. Finally, the Galvanic Isolation safeguards sensitive upstream microprocessor components against accidental field voltage spikes.

Important Considerations and Precautions

When handling or replacing the AWT200048, adhering to Electrostatic Discharge (ESD) Protections is critical; the onboard microchips are highly sensitive, so technicians must wear a grounded wrist strap when removing the module from its anti-static packaging. Before installing or extracting the board, ensure that All Power to the Analyzer is Disconnected; hot-swapping non-designated internal boards can cause an electrical arc that destroys the backplane connector pins.

Care must be taken during alignment to ensure the Multi-Pin Edge Connectors are perfectly straight before applying pressure, as bent pins will cause permanent communication faults. Furthermore, because this module relies on the analyzer housing for environmental protection, ensure the enclosure's Rubber Gaskets are Intact and Clean during reassembly to maintain the NEMA 4X or IP66 rating against moisture ingress.

Product Applications

The AWT200048 is deployed anywhere ABB's premium analytical transmitters are used to manage water quality and chemical composition.

• Municipal Water Treatment: Monitoring pH, turbidity, and chlorine levels in drinking water purification systems.

• Wastewater Treatment Plants: Managing dissolved oxygen and pH in aeration basins to optimize biological treatment processes.

• Power Generation Clean Rooms: Monitoring ultra-pure water conductivity to prevent scale and corrosion in high-pressure steam boilers.

• Chemical and Petrochemical Processing: Serving as the signal processing hub for inline analyzers tracking chemical concentration or effluent neutralization.

• Pharmaceutical and Biotech Production: Assisting in the precise monitoring of fermentation batches where strict chemical parameters must be maintained.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！
