AI890 ABB

Product Dimensions：

The AI890 functions as an 8-channel analog input interface that supports standard 4-20 mA signals. Its primary role is to provide a safe galvanic isolation barrier between the hazardous field environment and the non-hazardous control system backplane. The module is typically mounted on a Terminal Termination Unit (TU890 or TU891), which provides the physical connection points for field wiring. Because the isolation is integrated directly into the module, there is no need for external zener barriers or galvanic isolators, which significantly simplifies the cabinet layout and reduces the total footprint of the control system.

Product Parameters

• Number of Channels: 8 isolated analog input channels.

• Input Signal Range: 4 to 20 mA (supports HART pass-through communication).

• Isolation: Individual galvanic isolation for each channel, providing high immunity against ground loops and noise.

• Resolution: 12-bit analog-to-digital conversion.

• Power Supply: Powered via the ModuleBus (24 VDC nominal).

• Intrinsically Safe Protection: Certified for connection to sensors in Class I, Div 1, or Zone 0/1 hazardous areas (Ex ia IIC).

• HART Support: Full transparency for HART digital communication, allowing for remote instrument configuration and diagnostics.

• Power Dissipation: Approximately 2.5 Watts during normal operation.

• Temperature Range: Operating limits typically between 0°C and 55°C.

Product Advantages

A major advantage of the AI890 is its Integrated Intrinsically Safe Barrier. By combining the I/O function and the safety barrier into a single module, users save significant space in the electrical room and reduce the number of potential failure points in the wiring. The HART Connectivity is another standout feature, enabling the control system to access secondary variables and diagnostic data from "smart" field transmitters without additional hardware.

Furthermore, the module offers High Channel Density, allowing for 8 isolated inputs in a very narrow form factor. The Galvanic Isolation between channels ensures that a fault or short circuit on one field loop does not propagate to other channels or damage the central controller. This level of robustness is essential for maintaining high process availability in critical industrial plants.

Important Considerations and Precautions

When installing the AI890, the most critical precaution is the Separation of IS and Non-IS Wiring. Field cables from hazardous areas must be routed in separate conduits or wire ducts from standard power and control cables to prevent energy induction that could bypass the safety barriers. Terminal Unit Selection is also vital; the AI890 must be paired with the correct TU890 series termination unit to maintain its safety certifications.

Technicians must ensure that the Total Loop Resistance (including the sensor, wiring, and module input impedance) does not exceed the driving capability of the field transmitter. Because this is an intrinsically safe device, any Maintenance or Testing must be performed using tools and procedures certified for hazardous areas to avoid creating a spark. Finally, always verify the Firmware Compatibility between the AI890 and the CI801 or CI840 Cluster Communications Interface to ensure all diagnostic features are fully functional.

Product Applications

The ABB AI890 is specifically used in industries where flammable gases, vapors, or liquids are processed.

• Oil and Gas Extraction: Interfacing with pressure and level transmitters on offshore platforms and wellhead sites.

• Chemical Processing: Monitoring flow and temperature sensors in reactor vessels and storage tanks where explosive mixtures may occur.

• Pharmaceutical Manufacturing: Used in solvent recovery areas and cleanrooms where volatile organic compounds (VOCs) are present.

• Fuel Storage Terminals: Connecting tank gauging systems and leak detection sensors to the central DCS.

• Distilleries and Alcohol Production: Managing process variables in areas with high ethanol vapor concentrations.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！

ABB SDCS-PIN-H11A  3ADT319200R1501

ABB SDCS-PIN-3A 3ADT312200R1

ABB AMC-DC  3ADT309900R1

ABB SDCS-CON-2 3ADT309600R1

ABB SCYC51220

ABB SDCS-CON-2A  3ADT309600R0002

ABB ZCON-12

ABB SDCS-PIN-41A  3BSE004939R1

ABB SDCS-COM-81  3ADT314900R1002

ABB SDCS-COM-1  3BES005028R1

Colour：new                                  Warranty: 12 months

Lead Time：3-day working day     Price: Please contact us

Shipping Port: Xiamen, China       Payment:T/T

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online servi
