171CCC98030 SCHNEIDER

171CCC98030 SCHNEIDER Input module

Brand：SCHNEIDER Model number：171CCC98030

Country of origin: France Product weight：0.55kg

HS code：853710119

Product Details：

Product Dimensions：

The 171CCC98030 is an M1 Processor Adapter that features a built-in communication port for Interbus networks. It serves as the central intelligence for a Modicon Momentum station, mounting directly onto various I/O bases. This modular approach allows users to mix and match the processor with different I/O configurations depending on the specific sensor and actuator requirements of the machine. It is programmed using standard Schneider Electric software tools like Concept, ProWORX, or Unity Pro (EcoStruxure Control Expert), supporting standard IEC 61131-3 programming languages.

Product Parameters

Processor Type: M1 Processor Adapter
Communication Interface: Built-in Interbus (Remote Bus)
Memory Capacity: Includes $512 \text{ KB}$ of Flash memory and $256 \text{ KB}$ of RAM for user programs and data storage.
Clock Frequency: $20 \text{ MHz}$ internal clock speed.
Network Capabilities: Can act as a master or a slave on an Interbus network, depending on the configuration.
Internal Power Consumption: Typically $500 \text{ mA}$ at $5 \text{ VDC}$ from the backplane.
I/O Capacity: Supports up to 8192 bits of input and 8192 bits of output data over the network.
Diagnostic Indicators: Equipped with LED status lights for Module Ready (Run), Error, and Network Activity.

Product Advantages

One of the primary advantages of the 171CCC98030 is its Modular Form Factor. By separating the processor from the I/O base, maintenance becomes much simpler; the processor can be replaced without disturbing the field wiring on the base. The Distributed Intelligence capability allows this module to handle local logic processing, which reduces the load on a central controller and improves system response times.

Furthermore, the Interbus Integration provides a high-speed, deterministic serial bus system that is highly effective for industrial automation where timing is critical. Its Compact Size makes it a perfect fit for small control cabinets or mounting directly on machinery where space is at a premium.

Important Considerations and Precautions

When deploying the 171CCC98030, it is vital to ensure Firmware Compatibility between the processor and the programming software version being used. An outdated firmware can lead to communication errors or unsupported function blocks. During installation, users must verify the I/O Base Compatibility; while the processor is versatile, it must be mechanically and electrically matched to the correct Momentum I/O base.

Electrostatic Discharge (ESD) precautions are mandatory when handling the module, as the exposed connector pins are sensitive to static electricity. Additionally, ensure that the Network Termination for the Interbus line is correctly configured; improper termination is a frequent cause of intermittent network failures and data corruption. Finally, always maintain a Current Backup of the program on a separate storage device, as the internal RAM relies on the system power or a battery for data retention.

Product Applications

The Schneider 171CCC98030 is commonly used in decentralized automation architectures across various industries.

Conveyor Systems: Managing local motor control and sensor feedback in large-scale distribution centers.
Packaging Machinery: Controlling specialized functions like heat sealing, labeling, and counting in high-speed lines.
Water Treatment: Handling local pump control and chemical dosing logic in remote telemetry stations.
Material Handling: Used in automated guided vehicle (AGV) systems for local navigation and safety logic.
HVAC Systems: Controlling large-scale air handling units and chillers where distributed I/O reduces wiring costs.
