170ADI34000 SCHNEIDER Input module

Brand：SCHNEIDER Model number：170ADI34000

Country of origin: France Product weight：0.55kg

HS code：853710119

Inquire Now

Product Details：

Product Dimensions：

The Schneider Electric Modicon Momentum 170ADI34000 is a discrete input base module designed for the Modicon Momentum distributed I/O architecture. It features 16 discrete input channels operating at 24 VDC, functioning as an interface between field sensing devices—such as limit switches, pushbuttons, proximity sensors, and photoelectric eyes—and the central programmable logic controller (PLC) or communication adapter. Built on a compact and modular block design, the module integrates directly with standard Momentum communication options or processor adapters, making it an efficient solution for distributed automation, machine control, and remote I/O field expansion.

Product Parameters

Product Family: Modicon Momentum automation platform
Module Type: Discrete input base module
Number of Inputs: 16 discrete channels organized in a single group
Nominal Input Voltage: 24 VDC
Input Voltage Range: 11 VDC to 30 VDC for active state (Logic 1), -3 VDC to 5 VDC for inactive state (Logic 0)
Discrete Input Logic: Positive logic (sink/source depending on field wiring setup)
Input Current: Typically 4 mA to 7 mA per input channel at 24 VDC
Response Time: Turn-on time less than 1 ms, turn-off time less than 1 ms
Isolation: 500 VAC channel-to-bus galvanic isolation
Power Dissipation: Low power consumption, typically under 2.5 W maximum
Status Indicators: LED status indicators for power, module health, and individual channel logic states (1 through 16)
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% non-condensing

Product Advantages

The Modicon Momentum 170ADI34000 offers high reliability and fast response times, ensuring swift signal processing for critical machine inputs and automation feedback loops.

Its compact footprint saves significant space inside control cabinets and localized junction boxes, reducing overall enclosure costs.

The modular architecture allows effortless snapping onto various Momentum processor adapters or communication option adapters, enabling flexible integration into Ethernet, Modbus, Profibus, or Interbus network topologies.

Clear front-facing LED status lights simplify diagnostic procedures and field troubleshooting by providing instant visual confirmation of input signals and hardware health.

Additionally, low power dissipation reduces heat generation within the control panel, extending component life and increasing operational stability in industrial environments.

Important Considerations and Precautions

Proper wiring practices must be strictly maintained, ensuring field signal wiring is separated from high-voltage AC power lines to minimize electromagnetic interference and signal noise.

Operating parameters must remain within specified limits, specifically avoiding overvoltage conditions above 30 VDC to protect input channels from permanent damage.

Power must be disconnected from the system prior to installing, removing, or wiring the module to prevent electrical shock or damage to the backplane pin connectors.

Adequate cabinet ventilation should be provided to ensure ambient temperatures remain strictly within the 0°C to 60°C operational window.

Firm terminal connections and correct terminal block alignment are necessary to prevent intermittent signal losses or loose wire faults caused by machine vibration.

Product Applications

The 170ADI34000 module is widely deployed across automated manufacturing, material handling, and process control industries.

Material Handling and Conveyor Systems: Monitoring pallet position sensors, optical photo-eyes, emergency stops, and conveyor jam detection limit switches.
Packaging Machinery: Processing high-speed sensor inputs for capping, labeling, sorting, and carton inspection stations.
Factory Automation and Assembly Lines: Interfacing pushbuttons, presence detection sensors, and safety door interlocks directly with distributed controller networks.
Water and Wastewater Treatment: Collecting digital state signals from float switches, valve position switches, and flow indicators in remote pump stations.
HVAC and Building Infrastructure: Monitoring pump running statuses, filter pressure switches, and damper limit indicators in centralized facility management systems.
