BM600212 B/M-60021-2 RELIANCE

Reliance BM600212 B/M-60021-2 Analog Output Modules

Brand：RELIANCE Model number：BM600212 B/M-60021-2

Country of origin: United States Product weight：0.55kg

HS code：9032899099

Product Details：

Product Dimensions：

Reliance (now Rockwell Automation) Analog Output Modules are crucial components in industrial control systems, responsible for converting digital signals from a controller (like a PLC or PAC) into continuous analog electrical signals. These analog signals are then used to precisely control various industrial devices that require variable input, such as motor speeds, valve positions, or heater power.

Product Details

Functionality:

Analog output modules act as Digital-to-Analog Converters (DACs). They receive digital values (e.g., from a PLC's internal memory or calculation) and transform them into corresponding analog voltage or current outputs.
These continuous analog signals allow for fine-tuned control of process variables, enabling more precise regulation than simple on/off control.

Common Output Types:

Voltage Outputs: Typically 0-10V DC, ±5V DC, ±10V DC. These are used for devices that respond to voltage levels.
Current Outputs: Most commonly 4-20mA. The 4-20mA standard is popular in industrial environments due to its inherent noise immunity and ability to detect wire breaks (0mA indicates a fault).

Resolution:

Analog output modules have a specified resolution, typically 12-bit, 16-bit, or higher. This refers to the number of discrete steps the digital signal can be divided into to produce the analog output. Higher resolution means finer control and greater accuracy. For example, a 12-bit module can output 4096 distinct values.

Channels:

Modules are available with varying numbers of output channels (e.g., 2-channel, 4-channel, 8-channel modules), allowing a single module to control multiple devices.

Isolation:

Many analog output modules feature isolation between the control circuitry and the field wiring. This protects sensitive control electronics from electrical noise, ground loops, and transient surges in the field, enhancing system reliability and safety.

Product Parameters

Output Ranges:

Voltage: 0-5V, 0-10V, ±5V, ±10V DC (common ranges).
Current: 0-20mA, 4-20mA (common ranges).

Resolution:

Typically 12-bit, 14-bit, 16-bit, or 18-bit.

Accuracy:

Expressed as a percentage of full scale output, indicating how close the actual output is to the ideal output.

Load Resistance:

The maximum or minimum resistance the output can drive (for current outputs) or the minimum impedance it can drive (for voltage outputs).

Settling Time:

The time it takes for the output signal to reach and stabilize within a specified percentage of its final value after a change in input.

Channel-to-Channel Isolation:

If applicable, the electrical isolation between individual output channels.

Operating Temperature:

Standard industrial temperature range, typically -25°C to 70°C.

Power Consumption:

The electrical power required for the module to operate.

Module Slot Requirements:

Specifies which type of backplane or chassis slot the module can be installed in within the control system architecture (e.g., AutoMax rack, DCS 5000 rack).

Product Advantages

Precise Control:

High resolution and accuracy enable very fine and accurate control over process variables, leading to optimized system performance.

System Integration:

Designed to integrate seamlessly with Reliance/Rockwell Automation control platforms (PLCs, PACs), simplifying system design and programming.

Robustness:

Built to withstand harsh industrial environments, offering long-term reliability and reducing maintenance needs.

Isolation:

Electrical isolation helps protect the control system from field wiring issues, enhancing system stability and longevity.

Flexibility:

Support for various output types (voltage and current) and ranges makes them versatile for different actuator requirements.

Diagnostic Capabilities:

Often include LEDs or software-based diagnostics for easy troubleshooting and status monitoring.

Important Considerations

Compatibility:

Ensure the analog output module is compatible with your specific Reliance Electric (or Rockwell Automation) controller and backplane/chassis. This is crucial for proper communication and operation.

Output Requirements:

Verify that the module's output range, type (voltage/current), resolution, and load driving capabilities meet the specifications of the field devices you intend to control.

Environmental Conditions:

Adhere to the specified operating temperature, humidity, and vibration limits to ensure the module's long-term performance and reliability.

Wiring Practices:

Proper wiring (shielding, grounding, wire gauge) is essential to minimize noise interference and ensure accurate signal transmission. Consult the module's installation manual.

Power Supply:

Provide a stable and clean power supply within the specified voltage range.

Calibration:

For applications requiring high precision, regular calibration of analog output modules and connected devices may be necessary.

Safety Interlocks:

Always implement appropriate safety interlocks and emergency stop procedures independent of the analog control loop.

Product Applications

Process Control:

Controlling flow rates with proportional valves, regulating temperature with heating elements, or adjusting pressure.

Motor Speed Control:

Sending speed reference signals to Variable Frequency Drives (VFDs) for precise motor speed regulation in conveyors, pumps, and fans.

Positioning Control:

Controlling the position of actuators, robotic arms, or other mechanical systems that require proportional movement.

Environmental Control:

Regulating humidity in climate control systems, or controlling fan speeds in ventilation systems.

Test and Measurement:

Generating specific voltage or current signals for testing other electronic equipment or for calibration purposes.

Mixing and Dosing:

Precisely controlling the amount of liquid or material being added in mixing processes.

BM600212 B/M-60021-2 RELIANCE

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
