Reliance 0-56940-512 Analog Input Module

Brand：RELIANCE Model number：0-56940-512

Country of origin: United States Product weight：0.55kg

HS code：9032899099

Product Details：

Product Dimensions：

Reliance Electric, now a part of Rockwell Automation, manufactured a range of industrial automation components, including analog input modules. These modules are crucial for control systems, converting continuous analog signals from field devices into digital data that a Programmable Logic Controller (PLC) or other control system can understand and process.

Product Details

Functionality: RELIANCE Analog Input Modules are designed to measure and convert a variety of analog signals from sensors and transducers into a digital format. These signals typically represent physical quantities like temperature, pressure, flow, level, speed, or voltage.
Signal Types: They commonly support standard industrial analog signals, such as:

Voltage signals (e.g., 0-10V, ±10V, 0-5V, ±5V, ±1V)
Current signals (e.g., 4-20mA, 0-20mA)
Thermocouples (e.g., Type J, K, T, E, R, S, B, N)
Resistance Temperature Detectors (RTDs)

Conversion: The modules perform Analog-to-Digital (A/D) conversion, transforming the continuous analog signal into discrete digital values that the control system can use for monitoring, control, and data logging.
Compatibility: RELIANCE Analog Input Modules were primarily designed to work with RELIANCE Electric's own control platforms, such as the AutoMax PLC system and DCS 5000. They typically interface with a local rack or backplane.
Isolation: Many modules feature isolation between input channels and/or between field wiring and the control system to prevent noise interference and protect sensitive electronics.
Filtering: Often include user-programmable filters to reduce signal noise and improve measurement accuracy.

Product Parameters (Typical for various models, actual specs vary by part number)

Input Channels: Available in configurations with varying numbers of channels (e.g., 2-channel, 4-channel, 8-channel).
Input Ranges: Specific voltage or current ranges supported (e.g., ±1V, ±5V, ±10V, 4-20mA).
Resolution: The precision of the A/D conversion, commonly 12-bit or 16-bit (plus sign for bipolar inputs). Higher resolution means finer measurement increments.
Conversion Rate/Update Period: How frequently the analog signal is sampled and converted. This can range from microseconds to seconds, depending on the module and configuration.
Accuracy: Typically expressed as a percentage of full scale (e.g., ±0.1%, ±1%).
Power Consumption: The electrical power required for the module to operate.
Operating Temperature: The ambient temperature range in which the module is designed to operate reliably (e.g., 0°C to 60°C).
Mounting: Designed for rack-mount or chassis-mount installation within the control system's enclosure.
Diagnostic Features: May include LED indicators for channel status or module health.

Product Advantages

Precision and Accuracy: Designed to provide precise and accurate conversion of analog signals, which is critical for effective process control.
Robustness: Built for industrial environments, offering durability and reliability in the face of temperature fluctuations, vibration, and electrical noise.
Compatibility (within Reliance systems): Seamlessly integrated with RELIANCE Electric's legacy PLC and DCS systems, ensuring easy setup and operation for existing installations.
Flexibility: Support for various input signal types and programmable features (like filtering and conversion rates) allows for adaptation to different sensor technologies and application needs.
Reliability: As part of a well-established industrial automation brand, these modules are known for their long-term operational stability.

Important Considerations

System Compatibility: Primarily designed for older RELIANCE Electric control systems. Modern systems might require specific gateway modules or different I/O solutions.
Availability: As RELIANCE Electric is now part of Rockwell Automation, new RELIANCE-branded modules might be limited. The market for these modules is largely in the secondary (used or refurbished) market.
Documentation: While manuals for many legacy RELIANCE products are available (often through Rockwell Automation's literature library), specific programming details or advanced troubleshooting might require deeper knowledge of the older systems.
Calibration: Analog input modules, especially for high-accuracy applications, may require periodic calibration to maintain optimal performance.
Noise Reduction: Proper wiring, shielding, and grounding practices are essential to minimize electrical noise interference with analog signals.
Replacement/Upgrade: For new installations or system upgrades, consider current Rockwell Automation (Allen-Bradley) or other contemporary I/O platforms, which offer enhanced features, connectivity, and support.

Product Applications

RELIANCE Analog Input Modules were widely used in various industrial sectors where continuous process variables needed to be monitored and controlled. Common applications include:

Process Control:

Monitoring temperature in furnaces, ovens, and chillers.
Measuring pressure in pipelines, tanks, and pneumatic systems.
Controlling flow rates in fluid transfer systems.
Monitoring liquid levels in storage tanks.

Motor Control Feedback:

Providing feedback for motor speed (from tachometers) and torque control in drive systems.

Factory Automation:

Acquiring data from sensors in various manufacturing processes for quality control and process optimization.

Energy Management:

Monitoring power consumption, voltage, and current in electrical distribution systems.

Water and Wastewater Treatment:

Measuring pH levels, dissolved oxygen, and flow rates in treatment processes.

HVAC Systems:

Monitoring environmental conditions like temperature, humidity, and airflow.

801592-70SC RELIANCE

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
