705358-68A RELIANCE

Reliance 705358-68A analog module

Brand：RELIANCE Model number：705358-68A

Country of origin: United States Product weight：0.55kg

HS code：9032899099

Product Details：

Product Dimensions：

Reliance analog modules are essential components in industrial automation systems. They act as the bridge between real-world analog signals (like voltage, current, temperature, or pressure) and the digital language of Programmable Logic Controllers (PLCs) or other control systems. These modules convert continuous physical measurements into digital data that the control system can understand and process, or convert digital commands from the control system into analog outputs to control devices.

There are generally two main types:

Analog Input Modules: These modules receive continuous signals from sensors (e.g., thermocouples, RTDs, pressure transducers, flow meters) and convert them into digital values that the PLC can use for monitoring, alarming, or control calculations.
Analog Output Modules: These modules take digital values from the PLC and convert them into continuous analog signals (e.g., 0-10V, 4-20mA) to control actuators like variable frequency drives (VFDs), proportional valves, or servo motors.

These modules are designed to operate reliably in harsh industrial environments, often featuring robust construction and isolation to protect sensitive electronics from electrical noise and ground loops.

Product Parameters

Specific parameters will vary widely depending on the exact module type and its intended application, but common parameters include:

Input/Output Ranges:

Voltage: Common ranges include 0-5V, 0-10V, ±5V, ±10V.
Current: Most commonly 0-20mA or 4-20mA.
Thermocouple Types: J, K, T, E, R, S, B, N.
RTD Types: Pt100, Pt1000, Ni120.

Resolution: Typically 8-bit, 12-bit, or 16-bit, which determines the precision of the analog-to-digital (ADC) or digital-to-analog (DAC) conversion. A higher bit count means finer resolution.
Number of Channels: The quantity of independent input or output points on a single module (e.g., 2, 4, 8, or 16 channels).
Isolation: Specifies whether the channels are electrically isolated from each other and from the backplane, crucial for noise immunity and protection.
Conversion Rate: How quickly the module can convert analog signals to digital data (e.g., samples per second or milliseconds per conversion).
Accuracy: The percentage deviation from the true value, often expressed as a percentage of the full-scale range.
Operating Voltage: The power supply required for the module (e.g., 24V DC).
Operating Temperature Range: The environmental temperature range the module can safely operate within (typically industrial grades like -25°C to 70°C).
Communication Interface: The bus or network protocol used to communicate with the main controller (e.g., part of a proprietary backplane, Ethernet/IP, Profibus, Modbus).

Product Advantages

Precise Measurement and Control: Analog modules enable fine-tuned control and accurate data acquisition, essential for processes requiring high precision.
Robustness: Designed to withstand the demanding conditions of industrial environments, including temperature fluctuations, vibration, and electrical noise.
Versatility: A wide variety of module types supports diverse sensor and actuator technologies, making them suitable for many applications.
Integration: Designed for seamless integration into larger control systems, often within a modular rack or chassis for easy expansion.
Signal Integrity: Often feature signal conditioning and isolation to ensure reliable and accurate data transmission, minimizing interference.
Diagnostics: Many modules include built-in diagnostics for easier troubleshooting and system maintenance.

Important Considerations

Signal Compatibility: Always verify that the module's input/output ranges and types match your sensors and actuators. Using the wrong type can lead to inaccurate readings or damage.
Resolution Requirements: Choose a module with sufficient resolution for your application's precision needs. Higher resolution modules are typically more expensive.
Environmental Factors: Ensure the module's operating temperature and environmental protection (e.g., IP rating) are suitable for its installation location.
Noise and Grounding: Analog signals are susceptible to electrical noise. Proper shielding, grounding, and wiring practices are critical for reliable operation.
Calibration: Analog modules may require initial and periodic calibration to maintain accuracy.
Software Configuration: Modules need to be properly configured within the PLC or control system's programming software to define input scaling, output ranges, and other parameters.
Compatibility with Control System: Ensure the module is compatible with your specific PLC or control platform, especially regarding communication protocols and backplane compatibility.

Product Applications

Reliance (and now Rockwell Automation) analog modules are widely used across various industries for precise monitoring and control:

Process Control:

Monitoring and controlling temperature in ovens, furnaces, and HVAC systems.
Measuring and regulating pressure in pipelines and tanks.
Controlling flow rates in liquid and gas processing.
pH level control in chemical processes.

Machine Control:

Speed control of motors using VFDs.
Positioning control in robotic arms or CNC machines.
Controlling hydraulic or pneumatic actuators with proportional valves.

Energy Management:

Monitoring power consumption (voltage, current, power factor).
Controlling power output in renewable energy systems.

Water and Wastewater Treatment:

Monitoring water levels, turbidity, and chemical dosages.
Controlling pump speeds and valve positions.

Test and Measurement:

Collecting data from various sensors for product testing and quality control.

N011C59S RELIANCE

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
