0-57170 RELIANCE

Reliance 0-57170 Termination Unit

Brand：RELIANCE Model number：0-57170

Country of origin: United States Product weight：0.55kg

HS code：9032899099

Product Details：

Product Dimensions：

A Termination Unit (TU) is essentially a terminal block assembly or panel designed to consolidate and organize the wiring from various field devices (sensors, actuators) before they connect to the sensitive input/output modules of a PLC or other control system. They are specifically engineered to provide a clean, secure, and reliable connection point, reducing the complexity of direct wiring to I/O cards.

Functionality:

Wiring Consolidation: Provides clearly labeled screw terminals or quick-connect points for field wiring, making installation and troubleshooting easier.
Signal Routing: Organizes multiple field signals into a structured format for connection to a single I/O module via a pre-fabricated cable.
Protection: Often includes fuse holders, surge protection, or isolation features to protect the I/O modules from field wiring faults, overcurrents, or voltage spikes.
Signal Conditioning (sometimes): Some advanced termination units may incorporate passive components like resistors or capacitors for basic signal conditioning or filtering.
Fieldbus Integration: In certain fieldbus systems (like Foundation Fieldbus), termination units might integrate power conditioners and impedance matching for proper network operation, as seen in the ABB FieldIT TU 900-NR4.

Design: Typically consists of a PCB (Printed Circuit Board) mounted with various terminal blocks, connectors (e.g., ribbon cable connectors to I/O modules), and possibly passive or active components, all enclosed within a robust housing suitable for industrial environments. They are often designed for DIN rail mounting within control cabinets.

Product Parameters

Specific parameters depend heavily on the module it's designed to interface with and its intended application:

Number of Channels/Points: Corresponds to the number of I/O points on the associated module (e.g., 8, 16, 32 channels).
Wiring Type: Screw terminals, spring clamp terminals, push-in terminals.
Wire Size Compatibility: Range of wire gauges that can be securely connected (e.g., 0.2 to 2.5 mm² / 24-12 AWG).
Voltage Rating: Maximum voltage for field signals (e.g., 24V DC, 120V AC, 230V AC).
Current Rating: Maximum current per terminal or per group of terminals.
Connection to I/O Module: Specific connector type (e.g., ribbon cable, D-sub, proprietary connector).
Isolation: Type of isolation (e.g., galvanic isolation) between field and system side.
Operating Temperature: Standard industrial ranges, typically -25°C to 70°C.
Dimensions and Weight: Varies based on channel count and features.
Environmental Protection: IP rating for dust and moisture ingress.

Product Advantages

Simplified Wiring: Drastically reduces wiring complexity by providing a neat and organized point for field connections, replacing individual wires to an I/O card.
Reduced Installation Time: Pre-wired cables between the termination unit and the I/O module save significant installation time and reduce wiring errors.
Improved Troubleshooting: Clearly labeled terminals and organized wiring make it much easier to identify and diagnose wiring faults in the field.
Enhanced Reliability: Robust terminals ensure secure connections, reducing the risk of intermittent faults caused by loose wires.
Protection: Offers a layer of protection for sensitive I/O modules against surges, overcurrents, or miswiring from the field.
Maintenance Efficiency: Facilitates easier module replacement; the I/O module can be swapped without re-wiring all the field devices.
Standardization: Promotes consistent wiring practices across installations.

Important Considerations

Compatibility: Ensure the termination unit is specifically designed and compatible with the particular Reliance (or now ABB/Baldor) I/O module it will be used with. Using incompatible units can lead to miswiring or damage.
Wiring Practices: While simplified, proper wiring techniques, including correct wire stripping length and torque for screw terminals, are still essential for reliable connections.
Environmental Suitability: Verify the unit's environmental ratings (temperature, IP rating) are appropriate for the specific installation location.
Fusing/Protection: If the termination unit includes fuse holders, ensure the correct fuse ratings are used for the connected devices.
Grounding: Proper grounding of the termination unit and connected shields is crucial for signal integrity and safety.
Documentation: Always refer to the manufacturer's technical documentation for detailed wiring diagrams, installation instructions, and specifications.

Product Applications

Reliance Termination Units are widely used across various industries where PLCs and DCS systems are deployed for automation and control:

Process Control: Connecting a multitude of sensors (temperature, pressure, flow) and actuators (valves, pumps) in chemical plants, oil & gas facilities, water treatment plants, and pharmaceutical manufacturing.
Discrete Manufacturing: Interfacing with proximity sensors, limit switches, solenoids, and motor starters on assembly lines, packaging machinery, and robotic cells.
Building Automation: Providing connection points for HVAC controls, lighting systems, and security sensors.
Power Generation & Distribution: Wiring to protection relays, transducers, and control devices within substations and power plants.
Material Handling: Connecting sensors and actuators on conveyor systems, automated storage and retrieval systems (AS/RS), and cranes.
Any Industrial Control Panel: Used in almost any application requiring a structured and reliable interface between field wiring and control system I/O.

0-55341 RELIANCE

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
