MXP80A-050-503-00 SEW

MXP80A-050-503-00 SEW Eurodrive Movitrans Inverter

Brand：SEW Model number：MXP80A-050-503-00

Country of origin: Germany Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

The MXP80A-050-503-00 is designed for demanding industrial automation tasks that require precise motion control and high power density. As part of the MOVIAXIS platform, it facilitates a modular approach to motion control, allowing multiple servo drives to be linked together, which optimizes cabinet space and improves energy efficiency through shared DC link energy. This specific model is a non-regenerative power supply unit, meaning it provides power to the bus but typically requires external braking resistors to dissipate excess energy during motor deceleration.

Product Parameters

Product Series: MOVIAXIS Multi-Axis Servo Inverter
Module Type: Power Supply Module (Supply Unit)
Nominal Current: $50\text{ A}$
Input Voltage: $3 \times 380\text{ V AC}$ to $500\text{ V AC}$
Input Frequency: $50\text{ Hz}$ to $60\text{ Hz}$
Output DC Link Voltage: Approximately $560\text{ V DC}$ to $700\text{ V DC}$ (depending on input voltage)
Peak Output Current: Typically up to $250\%$ of nominal current for short durations (e.g., $125\text{ A}$ )
Connection Type: Integrated DC bus bars for axis connection and screw terminals for AC input
Enclosure Rating: IP20 (designed for control cabinet installation)
Control Voltage: Requires an external $24\text{ V DC}$ supply for electronics

Product Advantages

Integrated Energy Management: By utilizing a shared DC link, energy generated by braking axes can be used by motoring axes within the same system, significantly reducing overall power consumption.
Compact Footprint: The modular design of the MOVIAXIS series allows for side-by-side mounting without clearance, saving substantial space in the electrical cabinet compared to individual standalone drives.
High Overload Capacity: The module is engineered to handle significant peak loads, making it ideal for applications with high-dynamic cycles and rapid acceleration/deceleration phases.
Simplified Wiring: The use of integrated bus bars for the DC link and system bus reduces the amount of manual wiring required, decreasing the risk of installation errors and speeding up commissioning.
Advanced Diagnostics: When paired with the MOVIAXIS system bus, the module provides comprehensive monitoring of the power supply status, DC link levels, and thermal conditions.

Important Considerations and Precautions

High Voltage Danger: The DC link maintains a high voltage (up to $800\text{ V DC}$ or more) even after the AC power is disconnected. Always wait at least 10 minutes for the capacitors to discharge and verify with a voltmeter before performing maintenance.
Thermal Management: The module generates heat during operation. Ensure the control cabinet has adequate ventilation or air conditioning and maintain the required clearance above and below the unit for airflow.
Braking Resistor Selection: Since this is a standard supply module, an appropriately sized external braking resistor must be connected to the DC link to prevent overvoltage trips during regenerative braking.
Grounding: Proper industrial grounding and shielding practices must be followed to prevent Electromagnetic Interference (EMI) and ensure the safety of personnel.
Component Compatibility: Ensure that the total power demand of all connected axis modules does not exceed the continuous power rating of the MXP80A supply unit.

Product Applications

The MXP80A-050-503-00 is typically used in complex, high-performance machinery where multiple motors must work in synchronization.

Robotics and Handling Systems: Powering multi-jointed robots or pick-and-place systems where several axes operate simultaneously.
Packaging Machinery: Used in high-speed wrapping, filling, and labeling machines that require rapid, synchronized movements.
Automotive Industry: Powering assembly lines, welding stations, and material transport systems.
Textile and Paper Processing: Applications involving synchronized rollers or winders where tension control and high precision are critical.
Food and Beverage: Automated processing lines requiring hygienic design and reliable, continuous operation in high-cycle environments.
