TED134030WL GE Fanuc

TED134030WL GE Fanuc Input module

Brand：General Electric Model number：TED134030WL

Country of origin: U.S. Product weight：0.55kg

HS code：8517623990

Inquire Now

Product Details：

Product Dimensions：

The GE TED134030WL is a high-performance Molded Case Circuit Breaker (MCCB) from the E150 product line. It is designed to provide reliable thermal-magnetic protection for industrial and commercial electrical systems. This specific model features a fixed-trip unit and is optimized for use in panelboards, motor control centers, and various feeder applications where dependable overcurrent and short-circuit protection are required.

Product Parameters

The technical profile of the TED134030WL is defined by its robust electrical ratings and physical dimensions:

Current Rating: 30 Amperes.
Number of Poles: 3-Pole configuration for three-phase systems.
Voltage Ratings: Supports up to 480V AC (Standard) and 600V AC (Maximum), with a DC rating of up to 500V DC.
Interrupting Capacity (AIC Rating): 18kA at 240/480V AC, 14kA at 600V AC, and 10kA at 500V DC.
Frame Type: E150 Frame.
Trip Technology: Thermal-Magnetic (Non-interchangeable).
Trip Function: LI (Long-Time and Instantaneous) protection.
Terminal Type: Includes "WL" suffix indicating factory-installed Copper/Aluminum (Cu/Al) line and load lugs.
Wire Range: Accommodates 14-3 AWG Copper or 12-1 AWG Aluminum wiring.
Dimensions: Approximately 6.31 inches in height, 4.13 inches in width, and 3.38 inches in depth.

Product Advantages

The TED134030WL offers several key benefits for industrial infrastructure:

Reliable Protection: The dual thermal-magnetic trip mechanism provides precise response to long-term overloads and high-level short circuits.
Versatile Installation: The unit is "Reverse Feed" capable, allowing for flexible wiring configurations within the electrical cabinet.
Enhanced Safety Ratings: It is HACR (Heating, Air Conditioning, and Refrigeration) rated and HID (High Intensity Discharge) listed, making it suitable for specialized commercial loads.
System Compatibility: Seamlessly integrates with GE A-Series panelboards, Spectra series enclosures, and Motor Control Centers (MCC).
Robust Construction: Designed for longevity in demanding environments with a standard 40°C temperature rating.

Product Applications

This circuit breaker is widely deployed in the following environments:

Commercial HVAC Systems: Providing protection for large-scale heating, ventilation, and air conditioning units.
Industrial Motor Feeders: Acting as the primary protective device for motor branch circuits and distribution networks.
Lighting Control: Protecting HID lighting circuits in warehouses, stadiums, and industrial plants.
Power Distribution: Used in panelboards and switchboards to protect downstream electrical loads.
Manufacturing Equipment: Integrated into control panels for industrial machinery requiring a 30A protective feed.

Important Precautions

To ensure safety and equipment longevity, the following guidelines must be observed:

Terminal Torque: Properly torque the lug screws to the manufacturer’s specifications. Loose connections can lead to overheating, arcing, and premature breaker failure.
Voltage Verification: Ensure the system voltage does not exceed the breaker’s maximum rating of 600V AC or 500V DC.
Load Compatibility: Verify that the total continuous load does not exceed 80% of the breaker's 30A rating unless the application is specifically rated for 100% continuous duty.
Environmental Limits: The breaker is calibrated for a 40°C ambient environment. Operation in significantly higher temperatures may require de-rating the current capacity.
Periodic Testing: Conduct regular visual inspections for signs of heat damage or discoloration and perform manual toggle tests to ensure the internal mechanism remains free and operational.
