X20CP1484 B&R

Product Dimensions：

The X20CP1484 is a member of the X20 Standard CPU family. It is built on an Intel Celeron processor architecture, providing significantly more computing power than entry-level PLCs. The module is designed to be mounted on an X20 backplane, allowing for seamless integration with a wide variety of X20 I/O modules. It features integrated Ethernet, USB, and RS232 interfaces, and supports the expansion of the system via X20 system buses. The "1484" model is specifically optimized for applications requiring a balance between high-speed logic execution and complex communication handling.

Product Parameters

The technical specifications of the X20CP1484 highlight its capability for demanding industrial environments:

• Processor: Intel Celeron $400 \text{ MHz}$ or equivalent low-power high-performance architecture.

• Memory: Equipped with $128 \text{ MB}$ DDR SDRAM for system operations and $512 \text{ kB}$ of SRAM for retentive data storage.

• Onboard I/O: Includes 30 digital inputs/outputs and 2 counter inputs directly on the module for basic tasks.

• Interfaces: Features one Ethernet port (10/100 Mbit/s), one USB 2.0 port, and one RS232 port for programming and peripheral connection.

• Slot Capacity: Supports up to three plug-in modules for communication expansions such as POWERLINK, CAN bus, or additional serial interfaces.

• Cycle Time: Capable of achieving extremely low task cycle times, down to $400 \text{ µs}$ depending on program complexity.

• Environmental Limits: Operating temperature range from $0^\circ\text{C}$ to $55^\circ\text{C}$ with horizontal mounting.

• Protection: Standard IP20 rating, suitable for control cabinet installation.

Product Advantages

The X20CP1484 offers several strategic benefits for machine builders and system integrators. First, its High Performance Density allows for complex control algorithms and high-speed motion control in a very narrow housing, saving valuable cabinet space. Second, the Flexible Scalability of the X20 system means the CPU can be expanded with hundreds of different I/O slices depending on the application's needs.

Third, the Integrated Maintenance features are superior; the module uses a standard CompactFlash card (sold separately) for software storage, allowing for "plug-and-play" CPU replacement without the need for a laptop. Finally, the Fanless Design ensures high reliability and reduced maintenance intervals, as there are no moving parts prone to wear or clogging from dust.

Important Considerations and Precautions

When working with the B&R X20CP1484, specific precautions must be followed to ensure longevity and safety. It is critical to Check Firmware Compatibility before installation, as the version of Automation Studio used must support the specific hardware revision of the CPU.

Regarding Power Supply, the X20 system requires a separate Power Supply module (such as the X20PS series) to provide power to the internal backplane and the I/O bus; the CPU cannot function in isolation. Users must also be careful with CompactFlash Handling; never remove the CF card while the "Run" or "Error" LEDs indicate that the system is writing data, as this can lead to file system corruption. Lastly, ensure that the Cooling Clearance is respected—maintain at least $30 \text{ mm}$ of space above and below the module to allow for natural convection, as the unit is fanless.

Product Applications

The X20CP1484 is found in a wide range of sophisticated industrial sectors:

• Packaging Machinery: Controlling high-speed wrapping, labeling, and filling lines where synchronized motion and fast I/O response are mandatory.

• Plastic Processing: Managing the complex temperature control loops and hydraulic or electric drive sequences in injection molding machines.

• Renewable Energy: Used in wind turbine control systems for pitch adjustment and grid synchronization due to its robust processing and communication capabilities.

• Material Handling: Coordinating automated storage and retrieval systems (ASRS) and complex conveyor networks via POWERLINK or CANopen.

• Assembly Lines: Serving as the central controller for automotive component assembly where multiple fieldbus systems must be integrated into a single control point.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！
