2090-SCEP0-2 Allen-Bradley

2090-SCEP0-2 Allen-Bradley Power Board

Brand：Allen-Bradley Model number：2090-SCEP0-2

Country of origin: United States Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

The Allen-Bradley 2090-SCEP0-2 is a high-performance Encoder Feedback Plug Kit manufactured by Rockwell Automation. This specialized connector is designed to interface with the Kinetix family of servo drives, specifically serving as a termination point for feedback cables. It allows the drive to receive critical positioning and speed data from the motor's encoder. The "0-2" designation typically refers to the specific orientation or shell size requirements for compatibility with particular drive series, such as the Kinetix 6000 or Kinetix 5500.

Product Specifications

Product Type: Encoder Feedback Plug Kit (Connector Kit)
Part Number: 2090-SCEP0-2
Connection Type: Solder-style or Crimp-style terminals (depending on the specific revision) for secure electrical contact.
Pin Configuration: Multi-pin circular connector designed to carry differential encoder signals, power for the encoder, and thermal switch data.
Compatibility: Primarily used with Allen-Bradley Kinetix 2000, Kinetix 6000, and Kinetix 7000 servo drive systems.
Shell Material: Robust metallic or high-grade polymer housing providing 360-degree shielding against electromagnetic interference.
Operating Temperature: Designed to match the industrial ratings of the Kinetix drive line, typically ranging from 0°C to 55°C.
Mounting Style: Drive-end mounting (plugs directly into the feedback port of the servo drive).

Product Advantages

Superior Signal Integrity: The connector kit features high-quality shielding capabilities that minimize electrical noise, which is vital for maintaining the accuracy of high-resolution encoder signals.
Rugged Industrial Design: Built to withstand the vibration and thermal cycling common in industrial automation environments, ensuring a long service life and reducing downtime.
Simplified Maintenance: By using a dedicated plug kit, technicians can easily disconnect or swap feedback cables without rewiring the entire drive terminal, facilitating faster machine repairs.
Precise Fitment: As an authentic Allen-Bradley accessory, it ensures a perfect mechanical fit with the drive's feedback port, preventing intermittent connections that can cause nuisance faults.

Important Considerations

Proper Shielding: It is crucial to properly terminate the cable shield to the connector shell. Failure to do so can lead to "Feedback Noise" faults or erratic motor behavior.
Soldering Precision: If the kit requires soldering, ensure that cold solder joints and solder bridges between pins are avoided, as these can damage the drive's sensitive feedback circuitry.
Voltage Sensitivity: Ensure the encoder feedback cable used with this plug is rated for the correct voltage (usually 5V or 9V DC) to prevent overheating or signal degradation.
Bend Radius: When assembling the cable with this plug, maintain the manufacturer’s recommended bend radius for the feedback wire to prevent internal conductor breakage.
Compatibility Check: Always verify that the "0-2" variant matches your specific drive's port layout, as different Kinetix generations may require different connector keying or shell sizes.

Product Applications

The 2090-SCEP0-2 is a critical component in any motion control system requiring precise positioning. Common applications include:

Robotic Arms: Providing the feedback loop necessary for multi-axis robots to perform accurate pick-and-place operations.
CNC Machining: Ensuring that the drive knows the exact position of the cutting tool at all times to maintain tight tolerances.
Packaging Machinery: Used in high-speed labeling, filling, and wrapping machines where timing and synchronization are paramount.
Automated Assembly Lines: Facilitating the communication between servo motors and drives in complex conveyor and sorting systems.
Printing Presses: Maintaining precise web tension and registration by providing constant speed and position updates to the controller.
