S30810-Q2191-C-8 SIEMENS

S30810-Q2191-C-8 Siemens Basis unit

Brand：SIEMENS Model number：S30810-Q2191-C-8

Country of origin: Germany Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

The S30810-Q2191-C-8 is an insertable peripheral card built for installation in the backplane chassis of Siemens Hicom 300 series and HiPath 4000 communication systems. It translates digital signals from the central switching fabric into signals compatible with endpoint devices or network trunks. Engineered with industrial-grade telecommunication hardware components, the card provides hot-swappable capability, allowing system administrators to perform maintenance or upgrades without disrupting the broader communication network.

Product Parameters

Product Type: Telecommunications Subscriber / Trunk Interface Module
System Compatibility: Designed for Siemens Hicom 300, Hicom 300E, Hicom 300H, and HiPath 4000 PBX systems
Part Number Structure: S30810-Q2191-C-8
Mounting Type: Slide-in card for standard Siemens PBX rack chassis backplanes
Form Factor: Proprietary Siemens PBX card footprint
Operating Voltage: Powered directly via the PBX backplane bus
Signaling Protocols: Supports standard Siemens digital/analog telephony signaling protocols

Product Advantages

A key advantage of the S30810-Q2191-C-8 is its Seamless Native Compatibility with legacy and enterprise-grade Siemens PBX platforms, ensuring proper synchronization and signal integrity across the network. Its Robust Hardware Reliability makes it suitable for mission-critical corporate communications that require continuous uptime. The module's Hot-Swap Capability allows technical staff to replace or reconfigure line cards without powering down the main system, minimizing system downtime. Additionally, its High Density Architecture enables efficient utilization of backplane slots in medium to large enterprise telephone exchanges.

Important Considerations and Precautions

When handling and installing the S30810-Q2191-C-8, Electrostatic Discharge (ESD) Protection is mandatory; technicians must wear grounded wrist straps to prevent damage to sensitive microcontrollers on the board. System Power and Slot Compatibility must be verified before insertion to prevent short circuits or communication bus collisions. During installation, the card must be fully aligned with the chassis guide rails and firmly seated into the backplane connector before securing the locking mechanisms. Because this module is part of a legacy system architecture, ensuring proper firmware compatibility between the line card and the main CPU processor of the PBX is necessary for correct detection and operation.

Product Applications

The Siemens S30810-Q2191-C-8 is deployed in enterprise and industrial voice networks that rely on Siemens telecommunication infrastructure.

Corporate Telecom Systems: Interfacing internal office telephone extensions with the main PBX switching matrix.
Industrial Facilities: Connecting remote site communication terminals and emergency phone stations to a centralized voice network.
Healthcare Facilities: Supporting reliable internal communication infrastructure in hospitals and medical centers.
Government and Public Infrastructure: Providing secure, dedicated voice channel connections across municipal or agency networks.
