Reliance LHPI-2 Relay Input Module

Brand：RELIANCE Model number：LHPI-2

Country of origin: United States Product weight：0.55kg

HS code：9032899099

Product Details：

Product Dimensions：

A Reliance (PLC) Relay Input Module is a component of a Programmable Logic Controller (PLC) system designed to receive discrete (on/off) signals from various field devices. Unlike direct digital input modules that use solid-state switching, relay input modules utilize electromechanical relays to provide enhanced isolation and flexibility for a wider range of input voltages and currents, especially from devices that might have voltage spikes or require true electrical separation.

Functionality: The primary function of a relay input module is to safely convert an electrical signal from an external device (like a push button, limit switch, or sensor with relay contacts) into a low-voltage, logic-compatible signal that the PLC's central processing unit (CPU) can understand. The internal relay physically opens or closes contacts, which is then detected by the module's internal circuitry and communicated to the PLC processor.
Key Features:

Electrical Isolation: The most significant feature. The electromechanical relay provides galvanic (physical) isolation between the higher voltage/current field wiring and the sensitive PLC internal circuitry, protecting the PLC from electrical noise, transients, and voltage differences in the field.
Voltage Flexibility: Can typically accept a wider range of input voltages (e.g., 24VDC, 120VAC, 230VAC) due to the relay's coil voltage rating.
Polarity Insensitivity (for AC inputs): For AC inputs, the relay doesn't care about polarity, making wiring simpler.
Status Indicators: Often include LED indicators for each input channel, showing the on/off status of the corresponding field device, which aids in troubleshooting.
Robustness: Relays are known for their resilience to voltage spikes and electrical noise, making these modules suitable for electrically noisy industrial environments.

Product Parameters

Specific parameters depend on the exact model (e.g., part of a Reliance Electric AutoMate series or other systems). General parameters include:

Input Voltage Range: Common ranges are 24V DC, 120V AC, 230V AC. Some modules may support a broader range.
Number of Inputs: Typically 4, 8, 16, or 32 channels per module.
Input Current: The small current drawn by the relay coil for activation (e.g., a few milliamperes).
On/Off Delay Time: The time it takes for the relay to switch and for the input signal to be registered by the PLC (typically in milliseconds).
Isolation Voltage: The dielectric strength between field wiring and the PLC backplane (e.g., 1500V AC).
Operating Temperature Range: Standard industrial temperature ranges (e.g., -25°C to 70°C).
Terminal Type: Screw terminals for connecting field wires.
Mounting: Often designed to snap into a PLC rack or mount on a DIN rail.

Product Advantages

Superior Isolation: Provides excellent electrical isolation, protecting the sensitive PLC electronics from harsh field conditions, surges, and ground loops. This is a significant benefit over solid-state inputs in certain applications.
Wide Voltage Compatibility: Can directly interface with a broad range of AC and DC field voltages, reducing the need for external voltage converters.
Simple Operation: Operates like a traditional electromechanical relay, which is often intuitive for technicians familiar with relay logic.
Robustness to Noise: Less susceptible to electrical noise compared to some solid-state inputs due to the physical switching action of the relay.
Cost-Effective for Certain Applications: Can be a cost-effective solution for applications where high switching speed isn't critical but electrical isolation and broad voltage tolerance are.

Important Considerations

Switching Speed: Relay input modules are generally slower than solid-state (transistor-based) input modules due to the mechanical nature of the relay. They are not suitable for high-speed counting or very rapid signal changes.
Mechanical Wear: As electromechanical devices, relays have a finite number of operations before their contacts wear out. While typically very high (millions of cycles), this is a factor for frequently switching inputs.
Contact Bounce: Relays can exhibit contact bounce (brief, rapid opening and closing of contacts when switching), which might require debouncing in the PLC program if not handled internally by the module.
Physical Size: Relay input modules can sometimes be physically larger than equivalent solid-state modules due to the space required for the relays.
Maintenance: While reliable, in very high-cycle applications, the relays might eventually need replacement, though modern modules are designed for longevity.

Product Applications

Reliance (PLC) Relay Input Modules are well-suited for applications where electrical isolation, robustness to noise, and compatibility with various field voltages are important, and where high-speed sensing is not required.

Conventional On/Off Control: Reading signals from limit switches, push buttons, selector switches, level switches, pressure switches, and temperature switches.
Motor Control Circuits: Receiving feedback signals (e.g., motor running status, overload trip) from motor control centers.
Lighting Systems: Monitoring the status of industrial lighting circuits.
Basic Machine Interlocking: Sensing the position of guards or status of machine components for safety interlocks.
Process Monitoring: Receiving discrete alarm signals from various process sensors.
Older or Noisy Industrial Environments: Ideal for applications where the field wiring might be long, susceptible to noise, or involve varying voltage levels.
