803456-21T RELIANCE

Product Dimensions：

A Reliance Digital Input Module is an electronic module designed to interface digital signals from field devices (such as switches, sensors, and pushbuttons) to a programmable logic controller (PLC) or other automation control system. It acts as a crucial interface, converting the on/off signals from these devices into a digital format that the control system's processor can understand and act upon.

Product Details

• Functionality: The primary function of a digital input module is to detect the state (on or off, high or low) of connected digital input devices. It then transmits this information to the PLC's processor, allowing the control program to monitor the status of the process or machine being controlled.

• Isolation: Many digital input modules incorporate electrical isolation (e.g., optical isolation) between the field wiring and the backplane of the control system. This isolation helps to protect sensitive control system components from voltage spikes, noise, and other electrical disturbances in the field.

• Filtering: Some modules may include filtering circuitry to reduce the effects of electrical noise or contact bounce from mechanical switches, ensuring a more stable and reliable input signal.

• Indicators: Typically, digital input modules feature LED indicators for each input channel. These LEDs provide a visual indication of the input status (e.g., an LED might light up when the corresponding input is active).

• Wiring Options: Modules are designed with various terminal block types (e.g., screw terminals, spring clamp terminals) to facilitate secure and convenient wiring of field devices.

Product Parameters

• Input Voltage Range: Specifies the range of voltage levels that the module can accept as a valid digital input signal (e.g., 24V DC, 120V AC). Different modules support different voltage levels to accommodate various field devices.

• Number of Input Channels: Indicates the number of independent digital input points that the module can handle (e.g., 8, 16, 32 channels).

• Input Type (Sinking/Sourcing): Defines the type of input circuitry. Sinking (NPN) inputs are activated when a current path is provided to a common ground, while sourcing (PNP) inputs are activated when a voltage is supplied to the input terminal from a positive source.

• Input Current: The current drawn by the input circuitry when the input is active.

• Response Time: The time delay between a change in the input signal and the module registering that change and making it available to the PLC.

• Isolation Voltage: The maximum voltage that the isolation barrier can withstand without breakdown.

• Operating Temperature Range: The range of ambient temperatures within which the module is designed to operate reliably.

• Power Consumption: The amount of power drawn by the module from the control system's backplane.

• Certifications: Compliance with relevant industrial standards and certifications (e.g., UL, CE).

Product Advantages

• Reliable Interface: Provides a dependable connection between field devices and the control system.

• Noise Immunity: Often includes features like isolation and filtering to minimize the impact of electrical noise.

• System Protection: Isolation helps protect the control system from field-side faults.

• Clear Status Indication: LED indicators simplify troubleshooting and system monitoring.

• Flexibility: Available with various voltage ranges and channel counts to suit different application needs.

• Ease of Wiring: Designed for convenient and secure field wiring.

• Integration: Seamlessly integrates with Reliance (now Rockwell Automation/Allen-Bradley) control systems.

Important Considerations

• Voltage Compatibility: Ensure that the input voltage rating of the module matches the output voltage of the field devices being connected.

• Sinking/Sourcing Compatibility: Select modules with the appropriate input type (sinking or sourcing) to match the requirements of the field devices and the control system's common.

• Channel Density: Choose a module with a sufficient number of input channels for the application's needs. Consider future expansion.

• Environmental Conditions: Verify that the module's operating temperature range and environmental ratings (e.g., humidity, vibration) are suitable for the installation environment.

• Wiring Practices: Follow proper wiring procedures and use appropriate wire types and termination methods.

• Grounding: Ensure proper grounding to minimize noise and ensure safety.

• System Power Requirements: Account for the module's power consumption when designing the control system's power supply.

• Documentation: Always refer to the specific product documentation for detailed specifications, wiring diagrams, and installation instructions.

Product Applications

• Monitoring Discrete Sensors: Detecting the state of limit switches, proximity sensors, pushbuttons, and other on/off sensors.

• Status Indication Feedback: Receiving signals indicating the status of actuators or other controlled devices.

• Safety Circuits: Interfacing with safety interlocks, emergency stop buttons, and other safety-related devices.

• Counting and Positioning: Reading signals from encoders or other digital feedback devices for basic counting or positioning tasks.

• General Machine Control: Providing input signals to the PLC that determine the sequence and operation of machinery.

• Process Automation: Monitoring the status of digital valves, alarms, and other discrete process signals.

• Building Automation: Interfacing with digital sensors for lighting control, occupancy detection, and other building systems.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！

RELIANCE ELECTRIC 802266-40

RELIANCE ELECTRIC 802420-T

RELIANCE ELECTRIC 803.65.00

RELIANCE ELECTRIC 803456-21T

RELIANCE ELECTRIC 814.22.00

RELIANCE ELECTRIC 8145150

RELIANCE ELECTRIC 84586-24R

RELIANCE ELECTRIC 86466-3R

RELIANCE ELECTRIC 86466-58S

RELIANCE ELECTRIC 86466-59S

Colour：new                                    Warranty: 12 months

Lead Time：3-day working day       Price: Please contact us

Shipping Port: Xiamen, China          Payment:T/T

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
