8014294RE RELIANCE

Reliance 8014294RE controller module

Brand：RELIANCE Model number：8014294RE

Country of origin: United States Product weight：0.55kg

HS code：9032899099

Product Details：

Product Dimensions：

A Reliance Electric controller module is a microprocessor-based system that automates industrial machinery. It operates by reading input signals from various sensors and devices, processing that information based on a user-created program, and then sending output signals to control actuators like motors, valves, or lights. The modules are built to be robust and reliable for continuous operation. They're often part of a larger rack or chassis system, allowing for modular expansion with I/O and communication modules.

Product Parameters

Specific parameters vary widely by model and series, but here are some common specifications:

I/O Capacity: The number of I/O points a controller can manage. For example, older AutoMate controllers could handle 64 digital I/O or 16 analog I/O, while more advanced models could handle up to 256 digital or 64 analog points.
Memory: The amount of non-volatile memory for storing the user's program and data. This is typically measured in kilobytes (e.g., 2K x 16).
Execution Speed: The rate at which the controller scans and executes the program. This is a key performance metric, often measured in milliseconds per thousand ladder logic elements (e.g., 4 ms/K).
Power Supply: The voltage required to operate the module, typically 120/240 VAC or 24 VDC.
Communication: The module's ability to communicate with other devices. This includes support for serial protocols like RS-232 and specialized industrial networks like Reliance's R-NET.
Programming: These modules are primarily programmed using ladder diagram language, a simple, graphical language based on relay logic.

Product Advantages

Durability: Reliance Electric products are known for their rugged industrial design. They're built to withstand harsh conditions, including vibration, extreme temperatures, and electrical noise, which is a major benefit in factory settings.
Reliability: These modules offer a high degree of reliability, which is crucial for continuous production and minimizing costly downtime.
Precision Control: Specialized drive controller modules provide excellent control over motor speed, torque, and position, which is essential for many manufacturing processes.
Simplified Programming: For users familiar with relay logic, the ladder diagram programming language is intuitive and easy to use.
Legacy Support: Due to their long lifespan and continued use in many industries, there's still a market for refurbished modules and specialized technical support for legacy systems.

Important Considerations

Obsolescence: As legacy products, most Reliance Electric controllers are no longer manufactured. Sourcing new modules can be challenging, and technical support from the original manufacturer is limited. This requires companies to maintain a stock of spare parts or plan for system upgrades.
Limited Modern Connectivity: Older controllers may not support modern industrial protocols like Ethernet/IP or PROFINET out of the box, which can complicate integration with newer systems.
Programming Limitations: The programming software for these modules may be outdated, requiring older operating systems and hardware to function properly.
Learning Curve: While easy for those with a relay background, the ladder logic syntax and system architecture may differ from modern PLCs, requiring specific training.

801429SC RELIANCE

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
