65248-2S RELIANCE

Reliance 65248-2S analog module

Brand：RELIANCE Model number：65248-2S

Country of origin: United States Product weight：0.55kg

HS code：9032899099

Product Details：

Product Dimensions：

A Reliance Analog Module (whether input or output) is an electronic interface designed to handle analog signals. Unlike digital signals which are simply on or off, analog signals represent continuous variations in physical quantities like temperature, pressure, flow, or speed.

Functionality:

Analog Input Modules: Convert analog voltage or current signals from sensors (e.g., thermocouples, RTDs, pressure transducers, flow meters) into digital values that the PLC can read and process. They typically include Analog-to-Digital Converters (ADCs).
Analog Output Modules: Convert digital values from the PLC into continuous analog voltage or current signals to control devices that require variable input (e.g., variable frequency drives (VFDs) for motor speed control, proportional valves, analog meters, heating elements). They typically include Digital-to-Analog Converters (DACs).

Key Features:

High Resolution: Often feature 12-bit or 16-bit resolution for precise conversion, allowing for fine control and accurate measurement of continuous variables.
Multiple Channels: Typically offer multiple input or output channels per module (e.g., 2, 4, 8 channels).
Signal Ranges: Support various standard industrial analog signal ranges (e.g., 0-10V, ±10V, 0-20mA, 4-20mA).
Isolation: Provide galvanic isolation between field wiring and the control system to prevent noise interference and protect sensitive electronics.
Filtering: Often include built-in analog or digital filters to reduce electrical noise and ensure stable signal readings.
Diagnostics: May feature LEDs for status indication and some models offer advanced diagnostics for fault detection.
Programmable Features: For input modules, this might include programmable input ranges, conversion rates, and filters. For output modules, it could involve scaling and output range selection.

Product Parameters

Specific parameters depend on the module model (e.g., 57C409 Analog Input Module, 57C410 Analog Output Module) but generally include:

Input/Output Ranges: Specific voltage (e.g., ±1V, ±5V, ±10V, ±20V) or current (e.g., 0-20mA, 4-20mA).
Resolution: (e.g., 12-bit, 16-bit, or 12-bit plus sign for bipolar signals). A higher bit count means finer increments of measurement or control.
Accuracy: Typically expressed as a percentage of full scale (e.g., ±0.1%, ±1%).
Number of Channels: (e.g., 2-channel, 4-channel, 8-channel).
Conversion Rate/Update Period: How quickly the module can convert or update signals (e.g., as fast as 500 microseconds).
Isolation Voltage: The dielectric strength between field wiring and logic common (e.g., 600V, 2500V).
System Power Requirements: The current draw from the PLC backplane power supply (e.g., +5V, ±15V).
Operating Temperature: Standard industrial ranges, typically 0°C to 60°C or -25°C to 70°C.
Mounting: Designed to plug into specific Reliance PLC (e.g., AutoMax or DCS 5000) rack backplanes.

Product Advantages

Precise Measurement and Control: High resolution and accuracy enable precise monitoring and fine-tuning of critical process variables, leading to better product quality and resource efficiency.
Flexibility: Supports a wide variety of analog sensors and actuators, making them adaptable to diverse industrial applications.
Noise Immunity: Galvanic isolation and filtering capabilities help reduce the impact of electrical noise, ensuring reliable signal integrity in noisy industrial environments.
Robust Design: Built to withstand the rigors of industrial settings, including temperature variations and electrical disturbances, contributing to system reliability.
Integration: Designed to seamlessly integrate within Reliance Electric's PLC platforms, simplifying system design and deployment.
Diagnostic Capabilities: LEDs and potential software-accessible diagnostics aid in quick troubleshooting of wiring or signal issues.

Important Considerations

Obsolescence: As legacy products, new Reliance Electric analog modules may be difficult to source. Users should consider spare parts availability and plan for potential system upgrades to modern platforms.
Calibration: Analog modules, especially input types, may require calibration to ensure accuracy. Refer to the specific module's manual for calibration procedures.
Signal Conditioning: While modules have some filtering, complex applications may require external signal conditioners to convert sensor outputs into standard voltage/current ranges or to further reduce noise.
Wiring Practices: Correct wiring (e.g., shielded cables for analog signals, proper grounding) is crucial to minimize noise and ensure accurate readings, especially over long distances.
Input/Output Ranges: Always match the module's specified input/output ranges to the sensor's output range or the actuator's input requirements to prevent damage or inaccurate operation.
Software Configuration: Proper scaling and configuration within the PLC's programming software are essential to correctly interpret analog input values and generate appropriate analog output values.

Product Applications

Reliance analog modules are fundamental to automating processes that involve continuous measurement and control:

Temperature Control: Monitoring temperature from thermocouples or RTDs in ovens, furnaces, or HVAC systems and adjusting heating/cooling elements via analog outputs.
Pressure Monitoring and Control: Reading pressure transducer signals in hydraulic or pneumatic systems and controlling proportional valves or pumps.
Flow Rate Measurement: Monitoring liquid or gas flow rates from flow meters and regulating pump speeds or valve openings.
Level Sensing: Measuring liquid or solid levels in tanks or silos using continuous level sensors.
Motor Speed Control: Providing analog setpoints to variable frequency drives (VFDs) to precisely control AC motor speeds in applications like conveyors, fans, or pumps.
Positioning Control: Driving actuators for precise positioning in machinery, often in conjunction with specialized motion controllers.
Process Instrumentation: Interfacing with a wide array of industrial instruments that output analog signals for process monitoring and data acquisition.

61C365 RELIANCE

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
