57C413B RELIANCE

Reliance 57C413B central processing unit

Brand：RELIANCE Model number：57C413B

Country of origin: United States Product weight：0.55kg

HS code：9032899099

Product Details：

Product Dimensions：

RELIANCE (Reliance Electric) Central Processing Units are the core components of their Programmable Logic Controllers (PLCs) and industrial control systems. These CPUs are designed to execute control programs, manage I/O operations, and facilitate communication within automated processes, providing the intelligence for various industrial applications.

Product Details

Functionality:

The primary function of a RELIANCE CPU is to process control logic written by engineers, typically in ladder diagram, function block, or structured text programming languages.
It manages the flow of data between input modules (sensors) and output modules (actuators), ensuring that the industrial process operates according to defined parameters.
CPUs also handle communication with other devices on a network (e.g., HMIs, other PLCs, SCADA systems) and perform self-diagnostics.

Architecture:

RELIANCE CPUs typically feature a modular design, fitting into a backplane or rack assembly alongside I/O modules, power supplies, and communication modules.
They contain a microprocessor, memory for program storage and data, and various interfaces for system bus and communication ports.

Key Features (General for RELIANCE CPUs):

Robust industrial design for harsh environments.
Real-time operating capabilities for deterministic control.
Support for various programming languages.
Integrated communication ports (e.g., serial, Ethernet in newer models).
Diagnostic indicators (LEDs) for status and fault conditions.
Memory for application programs, data, and system configurations.
Often include battery-backed RAM or non-volatile memory for program retention during power loss.

Product Parameters (Example for a typical RELIANCE CPU like AutoMate processors)

Processor Type: Specialized industrial microprocessor designed for control tasks.
Application Memory: Typically in kilobytes (KB) or megabytes (MB) for program storage (e.g., 8k x 16 words, up to several MB in more advanced models).
Execution Speed: Measured in milliseconds per scan cycle, indicating how quickly the CPU can execute the control program.
I/O Capacity: The maximum number of input/output points the CPU can manage, either locally or via remote I/O (e.g., up to 256 digital or 64 analog I/Os via local heads, or thousands with distributed I/O).
Communication Ports:

Serial ports (e.g., RS-232, RS-485) for local communication and programming.
Network ports (e.g., Ethernet/IP, Modbus TCP, proprietary industrial networks) for system integration.

Power Requirements: Typically 5V DC supplied from the backplane, which is powered by a system power supply (e.g., 24V DC, 120V AC, 230V AC).
Operating Temperature Range: Designed for industrial environments, typically -20°C to +70°C.
Storage Temperature Range: Wider range, often -40°C to +85°C.
Humidity: Non-condensing humidity tolerance, typically 5% to 95%.
Mounting Type: Rack-mount or panel-mount depending on the system design.
Certifications: Often bear industry certifications like UL, CE, and others relevant to industrial control.

Product Advantages

Reliability and Robustness: RELIANCE CPUs are built to withstand harsh industrial conditions, including extreme temperatures, vibration, electrical noise, and dust, ensuring continuous and dependable operation.
Real-time Performance: Designed for deterministic control, providing consistent and predictable response times critical for industrial processes.
Scalability: The modular nature of RELIANCE PLC systems allows for flexible expansion of I/O and communication capabilities by adding compatible modules.
Legacy Support: For existing RELIANCE systems, these CPUs provide continuity and replacement options for maintaining older but still functional installations.
Dedicated Control: Unlike general-purpose computers, industrial CPUs are optimized for control tasks, focusing on stability and precision rather than multimedia or user interfaces.
Diagnostic Capabilities: Built-in diagnostics and status indicators simplify troubleshooting and maintenance.

Important Considerations

Legacy Systems: Many RELIANCE CPUs are associated with legacy control systems (e.g., AutoMate series). While robust, their support and availability might be more specialized compared to modern PLCs. Compatibility with current software and networking standards should be verified.
Programming Software: Requires specific RELIANCE programming software (e.g., AutoMate programming environments) which may also be legacy and require specific operating systems or configurations.
Power Supply: Ensure a stable and correctly sized power supply unit for the CPU and the entire rack assembly.
Environmental Protection: While robust, ensure the installation environment does not exceed the CPU's specified temperature, humidity, and vibration limits. Use appropriate enclosures where necessary.
Firmware Management: Understand the procedure for firmware updates and potential compatibility issues with existing programs.
Grounding and Wiring: Proper grounding and noise-reducing wiring practices are crucial for stable operation in industrial environments.
Cybersecurity (for networked systems): For CPUs with network connectivity, implement appropriate cybersecurity measures to protect against unauthorized access or attacks.

Product Applications

RELIANCE CPUs, as part of their industrial control systems, have been widely applied across various sectors:

Discrete Manufacturing:

Machine control (e.g., packaging machines, assembly lines, presses).
Material handling (e.g., conveyors, robotics, automated storage and retrieval systems).

Process Control:

Chemical processing plants (e.g., batching, mixing, temperature control).
Water and wastewater treatment facilities (e.g., pump control, filtration).
Power generation (e.g., boiler control, turbine monitoring).

Automotive Industry:

Assembly line automation, body shop control, paint shop systems.

Food and Beverage:

Process control for mixing, bottling, and packaging.

Oil and Gas:

Pipeline control, wellhead automation, and refinery processes.

Building Automation:

HVAC control, lighting systems, and access control in large facilities.

0-49020-4 RELIANCE

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
