2DF4286 RELIANCE

Reliance 2DF4286 Analog Output Modules

Brand：RELIANCE Model number：2DF4286

Country of origin: United States Product weight：0.55kg

HS code：9032899099

Product Details：

Product Dimensions：

RELIANCE analog output modules are electronic components designed to convert digital control signals from a Programmable Logic Controller (PLC) or other control system into continuous analog signals. These analog signals, typically voltage or current, are then used to control various industrial devices that require proportional command, such as variable speed drives, proportional valves, or process controllers.

These modules act as the bridge between the precise digital world of a control system and the dynamic analog world of industrial processes. They translate a numerical value (e.g., 0-4095 for a 12-bit resolution) into a corresponding voltage (e.g., 0-10V DC) or current (e.g., 4-20mA) signal.

Product Parameters (Typical Examples)

While specific parameters vary greatly depending on the model, common characteristics include:

Number of Channels: Typically 1, 2, 4, or 8 independent output channels per module.
Output Signal Ranges:

Voltage: 0-5V DC, 0-10V DC, ±5V DC, ±10V DC.
Current: 0-20mA, 4-20mA.

Resolution: Common resolutions include 8-bit, 12-bit, or 16-bit. Higher resolution means finer control (e.g., a 12-bit module can divide the analog range into 4096 discrete steps).
Isolation: Often feature channel-to-channel or channel-to-backplane isolation (e.g., 2500V isolation) to protect the control system from electrical noise and ground loops in the field.
Accuracy: Specified as a percentage of the full-scale range (e.g., ±0.1% FSR).
Load Impedance: Minimum and maximum load impedance specifications for voltage and current outputs.
Conversion Time: The time it takes for the module to convert a digital value to an analog output signal (typically in milliseconds).
Power Supply: Usually powered by the PLC backplane or an external 24V DC supply.
Operating Temperature: Designed for industrial environments, typically -25°C to 70°C.
Protection: May include short-circuit protection on output channels.

Product Advantages

Precision Control: Analog output modules enable precise, proportional control of process variables, allowing for fine-tuning of operations.
Robustness: Designed for harsh industrial environments, offering high reliability and durability.
Signal Integrity: Often feature isolation to prevent noise interference and ensure clean signal transmission.
Flexibility: Various channel counts and output ranges make them adaptable to diverse application requirements.
Integration: Designed to seamlessly integrate with RELIANCE (and subsequently Rockwell Automation) PLC systems, simplifying system design and programming.
Diagnostic Capabilities: Some modules include LED indicators for quick status checks and troubleshooting.

Important Considerations

Compatibility: Ensure the module is compatible with your specific RELIANCE (or Rockwell Automation) PLC platform and rack.
Output Type and Range: Verify that the module's output signal type (voltage/current) and range match the requirements of the device you intend to control.
Resolution Requirements: Choose a module with sufficient resolution for the precision needed in your application. Higher resolution generally means higher cost.
Isolation Needs: Assess whether isolated outputs are necessary to protect sensitive electronics from ground loops or electrical noise.
Environmental Conditions: Confirm the module's operating temperature and environmental protection ratings are suitable for the installation location.
Wiring Practices: Follow strict wiring guidelines to minimize noise, ensure proper grounding, and avoid damage to the module or connected devices.
Load Requirements: Ensure the connected device's impedance or current draw is within the module's specified capabilities. Overloading can damage the module.
End-of-Life Status: For older RELIANCE modules, be aware of their "End-of-Life" (EOL) status. While still functional, support and new parts might be limited, often requiring reliance on the secondary market.

Product Applications

RELIANCE analog output modules are fundamental components in a wide array of industrial applications requiring proportional control:

Motor Speed Control: Controlling Variable Frequency Drives (VFDs) to precisely adjust motor speed in conveyors, pumps, and fans.
Flow and Pressure Control: Operating proportional valves to regulate fluid flow or gas pressure in pipelines and process vessels.
Temperature Regulation: Controlling heating elements or cooling systems in ovens, furnaces, and HVAC systems.
Positioning Control: Driving actuators for precise positioning in robotics or automated machinery.
Process Control: Regulating various parameters in chemical, pharmaceutical, food and beverage, and other manufacturing processes.
Lighting Control: Dimming or adjusting the intensity of industrial lighting.
Test and Measurement: Providing analog signals for calibration or testing purposes.

908FK0201 RELIANCE

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
