0-51378-25 RELIANCE

Reliance 0-51378-25 Analog Output Modules

Brand：RELIANCE Model number：0-51378-25

Country of origin: United States Product weight：0.55kg

HS code：9032899099

Product Details：

Product Dimensions：

RELIANCE (now often under the Rockwell Automation umbrella) analog output modules were designed to provide precise analog signals (typically voltage or current) to control various field devices in industrial automation systems. These modules act as the interface between the control system's digital logic and the analog control requirements of actuators, drives, valves, and other equipment.

Product Details

Functionality:

Analog output modules convert digital signals received from a controller (like a PLC) into proportional analog voltage or current signals.
These signals are then used to control the speed, position, flow rate, or other parameters of analog-controlled devices.

Types (Common Examples):

Voltage Output Modules: Provide a voltage signal, typically in ranges like 0-10V DC, ±10V DC, or other specific voltage ranges. These are used to control devices that accept voltage signals as their control input.
Current Output Modules: Provide a current signal, most commonly 4-20mA. This type of signal is widely used in industrial process control due to its noise immunity and ability to transmit signals over longer distances without significant loss.
Isolated Output Modules: Offer electrical isolation between the controller's backplane and the output channels. This isolation helps protect sensitive control circuitry from electrical noise, ground loops, and potential field device failures.

Key Features (Typical):

Multiple output channels per module (e.g., 2, 4, 8 channels).
High resolution digital-to-analog converters (DACs) for precise output signal generation (e.g., 12-bit, 16-bit resolution).
Configurable output ranges per channel.
इंडिकेशन LEDs for module and channel status.
Short-circuit protection on output channels.
Open-circuit detection.
Calibration capabilities.
Compatibility with specific RELIANCE/Rockwell Automation control platforms.

Product Parameters (Illustrative - Refer to Specific Model Datasheets)

Output Range (per channel):

Voltage: 0-10V DC, ±10V DC, 0-5V DC, etc.
Current: 0-20mA, 4-20mA, etc.

Resolution:

12-bit, 14-bit, 16-bit (determines the number of discrete output levels).

Accuracy:

Expressed as a percentage of the full-scale output range.

Settling Time:

The time it takes for the output to reach a stable value after a change in the digital input.

Load Impedance:

The permissible range of impedance for connected devices.

Isolation Voltage (for isolated modules):

The maximum voltage the isolation barrier can withstand.

Power Supply Requirements:

Voltage and current drawn by the module from the system backplane.

Operating Temperature:

The ambient temperature range within which the module can operate reliably.

Environmental Ratings:

IP (Ingress Protection) rating indicating resistance to dust and moisture.

Product Advantages

Precise Control: High-resolution DACs enable accurate and stable analog signal generation for tight control of field devices.
Reliability: Designed for industrial environments, offering robust performance and minimizing downtime.
Flexibility: Multiple channel options and configurable output ranges cater to diverse application needs.
Noise Immunity (especially current outputs and isolated modules): Ensures signal integrity in electrically noisy industrial environments.
System Integration: Designed to seamlessly integrate with RELIANCE/Rockwell Automation control systems.
Diagnostic Features: Status LEDs and potential fault detection capabilities aid in troubleshooting.

Important Considerations

Application Requirements: Carefully select modules based on the required output signal type (voltage or current), range, resolution, and the number of channels needed.
Load Characteristics: Ensure that the impedance of the connected analog devices is within the specifications of the output module.
Wiring: Use appropriate wiring practices, including proper shielding and grounding, to minimize noise and ensure signal integrity. Refer to the module's wiring diagrams.
Power Supply: Ensure the control system's power supply can adequately power the analog output modules.
Environmental Conditions: Install the modules in an environment that meets their operating temperature and humidity specifications.
Calibration: Regular calibration may be required to maintain the accuracy of the analog outputs. Follow the manufacturer's recommendations.
Safety: Adhere to all safety guidelines and warnings provided in the product documentation. Ensure proper electrical connections and grounding.

Product Applications

Motor Speed Control: Providing analog signals to variable frequency drives (VFDs) to control motor speed.
Valve Positioning: Controlling the opening and closing of proportional valves in process control applications.
Actuator Control: Positioning linear or rotary actuators in automated machinery.
Flow Rate Control: Outputting signals to control pumps or flow control valves.
Temperature Control: Driving analog inputs of temperature controllers or directly controlling heating/cooling elements.
Pressure Control: Providing control signals to pressure regulators.
Level Control: Controlling the level of liquids or materials in tanks and vessels.
Data Acquisition Systems: Outputting analog signals to drive recorders or other analog input devices for testing and monitoring.

DBU-400 RELIANCE

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！

RELIANCE ELECTRIC DBU-400

RELIANCE ELECTRIC 0-51378-25

RELIANCE ELECTRIC 0-57510

RELIANCE ELECTRIC 0-57C400-A

RELIANCE ELECTRIC 0-57C404-1E

RELIANCE ELECTRIC 0-57C407-4H

RELIANCE ELECTRIC 0-57C411-2

RELIANCE ELECTRIC 0-60002-6

RELIANCE ELECTRIC 0-60031-5

RELIANCE ELECTRIC 45C220B

Colour：new Warranty: 12 months

Lead Time：3-day working day Price: Please contact us
