UMK-SE11.25-1 PHOENIX

Phoenix UMK-SE11.25-1 Central Control Unit

Brand： PHOENIX Model number：UMK-SE11.25-1

Country of origin:Germany Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

The Phoenix Central Control Unit, integrated into advanced automation platforms such as the ILC 2050 BI, Catan series, or PLCnext Technology ecosystem, functions as the primary processing hub for industrial, room, and building infrastructure systems. It provides centralized processing, network coordination, real-time data orchestration, and seamless integration of field-level I/O modules with high-level supervisory networks.

Product Details

The Phoenix Central Control Unit acts as the brain of an automated system, executing control algorithms, managing fieldbus communication, and housing the core operating system. Designed to bridge Operational Technology with Information Technology, it often utilizes open software architectures like the Niagara Framework or Linux-based PLCnext runtime environment. The unit coordinates multi-protocol environments, enabling data exchange across various field devices, sensors, and cloud services. Its compact, DIN-rail-mountable form factor incorporates onboard communication interfaces, local diagnostic displays, and scalable expansion buses for local or distributed I/O connections.

Product Parameters

Processor System: High-performance ARM or multi-core embedded industrial processor.
Operating System Architecture: Open Linux-based platform or embedded Niagara Framework environment.
System Memory: High-capacity onboard RAM along with non-volatile flash memory for project storage and data logging.
Nominal Operating Voltage: 24 VDC industrial power supply input.
Network Interfaces: Multi-port Ethernet switches supporting 10/100/1000 Mbps with configurable LAN and WAN separation.
Serial Interfaces: Configurable onboard RS-485 and RS-232 serial ports for fieldbus communication.
Expansion Bus Support: Local inline bus expansion or Single Pair Ethernet extension interfaces supporting up to 63 expansion modules.
Protocols Supported: BACnet/IP, Modbus TCP/RTU, OPC UA, PROFINET, KNX, and MQTT.
Operating Temperature Range: -25°C to 60°C (-13°F to 140°F).
Degree of Protection: IP20 enclosure rating for control cabinet installation.

Product Advantages

A primary advantage of the Phoenix Central Control Unit is its open-architecture engineering, which allows developers to run standard IEC 61131-3 logic alongside high-level programming languages such as C++, C#, and Python.

Its extensive multi-protocol interoperability simplifies system integration by enabling direct communication between dissimilar field networks without requiring extra protocol gateways.

The high hardware processing capability allows local data analysis and edge computing, significantly reducing bandwidth demands on central SCADA or cloud infrastructures.

Built-in cybersecurity features, including secure boot, signed firmware updates, and integrated firewall capabilities, ensure robust defense against unauthorized network access.

The modular expansion capability permits incremental system growth, allowing engineers to scale I/O points and field buses without altering the core control logic.

Important Considerations and Precautions

When installing and programming the Central Control Unit, ensure that the 24 VDC power supply delivers clean, regulated voltage within specified tolerances to prevent unexpected CPU resets or data corruption.

Proper functional earthing and shielding on serial and Ethernet lines must be maintained to safeguard internal microprocessors against industrial electromagnetic interference and surge spikes.

The maximum allowable current draw on the local expansion bus must be calculated prior to adding expansion modules to prevent overloading the internal power bus.

All default passwords and network settings should be reconfigured immediately upon commissioning to maintain compliance with industrial cybersecurity standards.

Never insert or remove local expansion modules while the power supply is active, as hot-swapping on non-supported backplanes can damage electrical contacts and internal chips.

Product Applications

The Phoenix Central Control Unit is deployed across various automated control environments requiring high reliability and flexible networking.

Primary Building Infrastructure: Managing heating, ventilation, air conditioning, and centralized plant equipment in commercial and institutional facilities.
Industrial Edge Control: Processing localized machine data, performing analytics, and transmitting operational metrics to cloud platforms or enterprise ERP systems.
Energy Management Systems: Monitoring multi-channel power distribution, load shedding, and utility metrics across industrial sites.
Water and Wastewater Facilities: Controlling pump stations, filtration sequencing, and telemetry links over distributed geographic regions.
Smart Factory Automation: Interfacing specialized sensors, barcode readers, and robotics with higher-level execution networks via OPC UA and PROFINET.
