QUINT-PS/3AC/48DC/20 2320827 PHOENIX

The Phoenix Contact coupler for external connection functions as an expansion interface within the modular Inline I/O system platform. It bridges the local Inline backplane bus with external digital signals, serial fieldbus loops, or remote I/O sub-stations. By converting internal backplane communication into standard industrial interface signals, it allows seamless data transfer across long distances or between distinct electrical domains. The module mounts directly onto a standard DIN rail and snaps into place alongside other Inline I/O terminals, utilizing integrated local bus contact points for power and data transmission without requiring external inter-module wiring.

Product Parameters

• Module Type: Bus coupler / expansion interface module for external connectivity.

• Interface Options: Configurable for external serial communication, RS-485/RS-422, or dedicated external local bus extensions depending on the specific module sub-variant.

• Supply Voltage: 24 VDC nominal voltage supplied via the Inline main circuit or segment circuit.

• Permissible Voltage Range: 19.2 VDC to 30 VDC including ripple.

• Current Consumption: Typically 35 mA to 80 mA from the local backplane bus depending on connected load.

• Galvanic Isolation: 500 VAC testing voltage between the local backplane bus, supply voltage, and external interface signals.

• Transmission Speed: Auto-detecting or configurable baud rates up to 500 kbps or 2 Mbps on the local bus interface.

• Mounting Type: Standard DIN rail mounting (NS 35/7.5 or NS 35/15).

• Connection Method: Push-in or screw-clamp Inline plug connectors for reliable field wire attachment.

• Operating Temperature: -25°C to 60°C (-13°F to 140°F).

• Degree of Protection: IP20 enclosure rating for cabinet installation.

Product Advantages

A primary advantage of this coupler module is its compact width, which saves valuable panel space while enabling expanded system reach.

The integrated galvanic isolation protects sensitive central control electronics from high-voltage transients, ground loops, and electromagnetic noise originating from external field lines.

Tool-free installation through the Inline backplane plug system significantly speeds up mounting and reduces wiring complexity during panel building.

The clear diagnostic LED indicators on the front panel allow maintenance personnel to monitor power supply status, bus activity, and communication errors at a glance, minimizing system downtime.

Important Considerations and Precautions

Ensure that total power consumption of all connected downstream modules and external lines does not exceed the maximum current capacity of the Inline power feed terminal.

Shielded twisted-pair cables must be used for all external communication lines, and the cable shield must be properly grounded at the designated Inline shield connector to maintain EMC compliance.

Never install or remove the coupler module while the system is under power, as hot-swapping can cause electrical arcs and interrupt backplane data transmission.

Always observe correct polarity for the 24 VDC auxiliary supply to prevent damage to internal protection diodes.

Deploy the unit inside an IP54 or higher rated control enclosure to protect the IP20 housing from dust, moisture, and conductive contaminants.

Product Applications

Phoenix Contact couplers for external connection are widely deployed across automated manufacturing and processing facilities to bridge control cabinets with peripheral field equipment.

• Remote I/O Station Linking: Connecting distributed I/O racks installed on machinery modules directly to a primary central PLC control cabinet.

• Machine Tool and Robotics Interfacing: Transmitting control signals and diagnostic data between mobile robot cells or machine tools and stationary plant controllers.

• Building Automation and Infrastructure: Interfacing external energy meters, environmental sensors, and localized HVAC actuators with the main automation network.

• Process Plant Field Connectivity: Extending signal channels to hazardous or remote areas using isolated external communication loops in water, wastewater, and material handling applications.
