QUINT-PS/1AC/48DC/ 5 PHOENIX

The Phoenix Contact Gate Module is designed to continuously monitor physical guard locking mechanisms, emergency stops, and safety doors in automated machinery. It evaluates signals coming from safety switch contacts or semiconductor outputs and provides safety-related switching outputs to immediately isolate energy sources when a guard is opened. Depending on the exact system architecture, the module can operate as a stand-alone safety relay unit or as an expandable fieldbus gate module that passes diagnostic and status data from field devices directly to a higher-level programmable logic controller (PLC). Its compact DIN-rail mount design allows seamless integration into industrial control panels.

Product Parameters

• Supply Voltage: 24 V DC (typically within an allowable range of 19.2 V DC to 30 V DC).

• Nominal Current Consumption: Typically 40 mA to 100 mA depending on internal processing and output loading.

• Safety Inputs: Dual-channel safety inputs for connecting mechanical switches, non-contact magnetic switches, or RFID-coded safety sensors.

• Safety Outputs: High-capacity digital switching outputs (relay contacts or OSSD transistor outputs) rated for 24 V DC / up to 2 A per channel.

• Diagnostic Interfaces: Integrated LED indicators for channel status, supply voltage, fault states, and bus communication.

• Response Time: Fast safety response times typically under 20 milliseconds to trigger instantaneous shutdown upon guard breach.

• Safety Ratings: Capable of achieving Category 4, Performance Level e (PL e) according to EN ISO 13849-1, and Safety Integrity Level 3 (SIL 3) according to IEC 62061.

• Operating Temperature Range: -20°C to 55°C (-4°F to 131°F).

• Degree of Protection: IP20 enclosure rating designed for installation inside IP54 or higher control cabinets.

• Mounting Type: Standard NS 35 DIN rail mounting according to EN 60715.

Product Advantages

The module delivers exceptional reliability in high-risk industrial environments by utilizing redundant dual-channel internal processing to eliminate single-point safety failures.

Its integrated diagnostic features allow operators to quickly identify whether a trip was caused by an opened guard door, a wiring short, or an internal fault, thereby reducing machine downtime.

Flexible wiring options enable easy cross-wiring and daisy-chaining of multiple safety gate sensors without compromising the overall safety integrity level.

The compact housing footprint saves valuable space on the control panel DIN rail while maintaining high terminal density and clear channel labeling.

Pluggable screw or push-in spring-cage connection technology enables rapid installation, maintenance, and tool-free module replacement during servicing.

Important Considerations and Precautions

Before installation, wiring must be verified against the specific safety category requirements to ensure cross-circuit detection and short-circuit monitoring are properly configured.

Power supply units connected to the module must deliver protective extra-low voltage (PELV) or safety extra-low voltage (SELV) to maintain electrical safety compliance.

Ensure the operating ambient temperature inside the control cabinet remains within specified limits, as overheating can shorten the operational lifespan of electronic components.

External inductive loads connected to the switching outputs must be suppressed using appropriate freewheeling diodes or RC elements to prevent inductive voltage spikes from damaging the internal output switches.

Never bypass or bridge safety inputs during normal operation, as doing so completely invalidates the functional safety rating and poses severe hazards to machinery operators.

Product Applications

Phoenix Contact Gate Modules are widely applied in industrial automation systems where personnel protection around moving machinery is critical.

• Robotic Cell Enclosures: Monitoring interlocking safety doors and access gates around industrial robot arms to ensure motion halts immediately upon opening.

• Automotive Assembly Lines: Securing physical barriers, light curtains, and safety gates along conveyor lines and automated welding cells.

• Packaging Machinery: Protecting operators from dangerous rotating or clamping mechanisms on cartoners, wrappers, and palletizers.

• Material Handling and Logistics: Interfacing safety guard gates on high-speed sorting systems, automated storage and retrieval systems (ASRS), and elevators.

• Machine Tool Guarding: Controlling access doors on CNC milling machines, lathes, and metal stamping presses during operation.
