E/UK 1201442 PHOENIX

Phoenix E/UK 1201442 communication module

Brand： PHOENIX Model number：E/UK 1201442

Country of origin:Germany Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

A Phoenix Contact communication module operates as an intelligent interface node within an industrial automation architecture. It enables modular I/O systems (such as Axioline F, Inline, or Inline Block I/O) or standalone field devices to communicate across high-speed industrial networks. The module processes field-level data, converts protocol structures in real time, and ensures deterministic data exchange between field devices and central controllers. Designed for rugged environments, these modules feature compact housings, push-in or screw connection technology, and advanced diagnostic capabilities that allow operators to monitor network health and signal integrity continuously.

Product Parameters

Supported Protocol Standards: Options available for PROFINET, Ethernet/IP, Modbus TCP, PROFIBUS DP, CANopen, EtherCAT, and RS-232/RS-422/RS-485 serial communication.
Transmission Rates: Fast Ethernet variants support 10/100 Mbps with auto-negotiation and auto-crossing; fieldbus models support baud rates up to 12 Mbps depending on the protocol.
Supply Voltage: Nominal 24 VDC operating voltage with an allowable range typically between 19.2 VDC and 30 VDC.
Current Consumption: Low power demand, typically drawing between 50 mA and 250 mA depending on active interface usage and system load.
Connection Technology: Push-in technology or screw connection for field wiring, with RJ45 ports or M12 connectors for network links.
Operating Temperature Range: Industrial standard from -25°C to +60°C, with extended-range variants operating from -40°C to +70°C.
Storage Temperature Range: Standard range from -40°C to +85°C.
Permissible Humidity: 5% to 95% non-condensing during operation and storage.
Degree of Protection: IP20 protection class for cabinet mounting; IP65/IP67 ratings available for field-mounted variants.
Diagnostic Indicators: Multi-color LED status indicators for power supply, bus status, module errors, and channel-specific communication activity.

Product Advantages

Phoenix Contact communication modules offer exceptional flexibility by supporting a broad spectrum of industrial protocols, making them ideal for modernizing legacy systems or building open, scalable control architectures.

The compact DIN-rail mount design saves valuable cabinet space, while tool-free Push-in Connection Technology significantly reduces installation time and minimizes wiring errors.

Integrated web-based management and comprehensive LED diagnostics enable rapid commissioning, parameterization, and troubleshooting without requiring specialized programming software.

High electromagnetic compatibility (EMC) shielding and robust surge protection ensure reliable performance and uninterrupted data transmission in harsh electrical environments.

Important Considerations and Precautions

Before installation, verify that the module's supply voltage matches the specified limits of the 24 VDC power supply to prevent overvoltage damage.

Proper grounding of the DIN rail and shielding of network cables are mandatory to maintain signal integrity and avoid communication drops caused by industrial noise.

Always configure the network parameters, such as IP addresses or bus node numbers, correctly prior to connecting the module to an active industrial network to avoid address conflicts.

Ensure adequate ventilation inside the control cabinet to keep the ambient temperature within the specified operating range, particularly when modules are mounted side by side.

Never plug or unplug wiring connectors or bus connectors while the module is powered, unless the specific product line is explicitly rated for hot-swapping.

Product Applications

Phoenix Contact communication modules are deployed across a wide variety of industrial sectors to establish reliable network connectivity.

Factory Automation: Linking modular I/O stations, drive systems, and human-machine interfaces (HMIs) to central PLCs over PROFINET or Ethernet/IP networks.
Process Industry and Infrastructure: Connecting remote sensors, flow meters, and field transmitters in water treatment plants, energy distribution facilities, and chemical processing lines.
Machine Building (OEM): Integrating distributed sub-assemblies and specialized field devices into compact machine architectures using standardized fieldbus or Ethernet interfaces.
Building Automation and Energy Management: Interfacing power meters, circuit monitoring systems, and HVAC controllers with central SCADA or building management systems via Modbus TCP or serial protocols.
Transportation and Logistics: Enabling reliable data communication in automated storage and retrieval systems, conveyor lines, and traffic control infrastructure.
