Phoenix 2967015 analog module

Brand： PHOENIX Model number：2967015

Country of origin:Germany Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

Phoenix Contact offers analog modules across several core product families, including Inline, Axioline F, Axioline SE, and MINI Analog signal conditioners. In PLC and DCS architectures, these modules act as signal acquisition or generation nodes that handle high-accuracy analog measurements in harsh industrial environments. They incorporate advanced digital processing, signal isolation, and filtering capabilities to ensure reliable signal transfer between field sensors, actuators, and central control units. Phoenix Contact analog modules support various industrial network protocols, including PROFINET, EtherNet/IP, EtherCAT, and Modbus TCP, when paired with the appropriate bus couplers.

Product Parameters

Input Signal Types: Configurable 0-20 mA, 4-20 mA, ±20 mA, 0-10 V, ±10 V, 0-5 V, RTD elements (Pt100, Pt1000, Ni1000), and Thermocouples (Types J, K, T, E, R, S, B, N).
Output Signal Types: Standard 0-20 mA, 4-20 mA, 0-10 V, and ±10 V channels with short-circuit protection.
Resolution: High-resolution Analog-to-Digital and Digital-to-Analog conversion options ranging from 12-bit up to 16-bit accuracy.
Conversion Time: Rapid sampling and conversion speeds starting from less than 1 millisecond per channel depending on the selected filtering settings.
Electrical Isolation: High channel-to-channel and channel-to-bus galvanic isolation, typically rated up to 500 VAC or 1.5 kVAC depending on the module series.
Operating Voltage: Nominal 24 VDC power supply with wide input tolerance ranges.
Operating Temperature Range: Standard operational temperature coverage from -25°C to 60°C, with extended range variants rated from -40°C to 70°C.
Accuracy Class: High measurement accuracy with typical full-scale error margins below 0.1%.
Housing and Mounting: Compact DIN-rail mountable designs utilizing push-in or screw connection technology for rapid field wiring.

Product Advantages

Phoenix Contact analog modules stand out for their exceptional signal immunity and high operational reliability in environments with severe electromagnetic interference.

Their compact form factor maximizes control cabinet space, allowing high-density signal wiring without compromising thermal performance.

The integration of Push-in Connection Technology significantly reduces installation time and simplifies wiring maintenance without requiring specialized tools.

Comprehensive diagnostics features, such as wire-break detection, short-circuit monitoring, and range overflow/underflow reporting, allow real-time health monitoring and rapid troubleshooting.

Furthermore, module parameterization can be executed flexibly through software tools, network fieldbuses, or DIP switches, ensuring smooth commission and integration.

Important Considerations and Precautions

When installing and commissioning Phoenix Contact analog modules, proper wiring topology must be observed, including the use of shielded twisted-pair cables for all low-level analog signal lines.

Shield grounding must be implemented according to manufacturer guidelines to prevent ground loops while ensuring protection against electromagnetic noise.

Attention must be given to matching the configuration settings of the module—such as current versus voltage selection—with the connected sensor specifications prior to powering the unit, as misconfigurations can cause hardware damage or measurement errors.

Power supply quality should be verified to ensure ripple and noise remain within the specified operational tolerances.

Hot-swapping or replacing modules must only be performed on system platforms that explicitly support live-insertion to prevent backplane bus disruption or unexpected machine shutdown.

Product Applications

Phoenix Contact analog modules are deployed globally across diverse industrial processing and automation sectors.

Process Control Systems: Monitoring continuous variables such as pressure, temperature, flow, and level in chemical, petrochemical, and pharmaceutical plants.
Water and Wastewater Management: Measuring pH, conductivity, turbidity, and tank levels across treatment facilities and pumping stations.
Factory Automation and Machinery: Controlling proportional valves, variable frequency drives, and position feedback sensors on automated assembly and packaging lines.
Energy and Power Generation: Acquisition of operational parameter signals from transformers, turbines, and renewable energy distribution equipment.
Building Automation and HVAC: Interfacing temperature, humidity, and airflow sensors with centralized facility management controllers.
