2938879 QUINT-PS-100-240AC/24DC/40 PHOENIX

A Phoenix Contact Communication Processor operates as an expansion interface or standalone gateway module that manages data exchange between local control systems and external networks. Depending on the specific series, such as the Inline, Axioline, or PLCnext families, these processors enable seamless integration with protocols including PROFINET, Modbus TCP, Ethernet/IP, PROFIBUS, and serial interfaces like RS-232, RS-422, and RS-485. They handle protocol conversion, packet buffering, and data formatting internally, ensuring high throughput and reducing network latency. Built for demanding industrial environments, they offer plug-and-play network integration, integrated web-based management, and robust diagnostic capabilities.

Product Parameters

• Supply Voltage: 24 VDC nominal, with an operating range typically from 19.2 VDC to 30 VDC.

• Interface Types: Options for RJ45 Ethernet ports, D-SUB connectors for serial or fieldbus, and push-in spring-cage connection blocks.

• Supported Protocols: PROFINET, Modbus TCP/RTU, Ethernet/IP, PROFIBUS DP, CANopen, and serial ASCII communications.

• Transmission Speed: Ethernet interfaces support 10/100/1000 Mbps auto-negotiation; serial interfaces support baud rates up to 115.2 kbps or higher depending on the standard.

• Operating Temperature Range: -25°C to 60°C for standard models, with extended temperature ranges available for harsh environments.

• Storage Temperature Range: -40°C to 85°C.

• Relative Humidity: 5% to 95% non-condensing during operation.

• Degree of Protection: IP20 rating designed for DIN rail mounting inside control cabinets.

• Diagnostic Indicators: Multi-color LEDs for system status, supply voltage, link/activity, and protocol-specific diagnostic alerts.

Product Advantages

Phoenix Contact Communication Processors deliver exceptional reliability by decoupling communication overhead from the primary control execution, preserving PLC processing power for motion and logic tasks.

Their modular hardware architecture allows straightforward installation on standard DIN rails and easy system expansion as network demands grow.

Comprehensive protocol compatibility ensures seamless bridging between legacy serial equipment and modern Industrial Ethernet networks without requiring complete system overhauls.

Integrated web management interfaces and standard diagnostic functions simplify commissioning, remote troubleshooting, and network monitoring, significantly reducing downtime.

Push-in wiring technology and industrial-grade noise immunity guarantee fast installation and reliable long-term operation in electrically harsh environments.

Important Considerations and Precautions

Ensure that the supply voltage matches the specified 24 VDC rating and is fed from a stabilized, surge-protected industrial power supply to prevent device damage.

Proper grounding of shield connections for communication cables is essential to prevent signal interference and electromagnetic noise disruption.

Always configure network IP settings, subnet masks, and baud rates correctly before connecting the processor to an active industrial network to avoid IP conflicts or bus faults.

Observe ventilation clearance requirements around the DIN rail module inside the control panel to maintain proper thermal dissipation during continuous operation.

Never install or disconnect signal wires or backplane module connections while power is applied to prevent electrical arcing and component degradation.

Product Applications

Phoenix Contact Communication Processors are deployed across a wide range of industrial automation sectors where cross-protocol communication and network expansion are required.

• Factory Automation: Interfacing specialized sensors, barcode readers, and motor drives with central PLC networks using Modbus or serial protocols.

• Process Engineering: Transmitting diagnostic data and process variables between distributed field devices and central SCADA control systems.

• Energy and Power Monitoring: Gathering energy consumption metrics from power meters and protection relays to transmit back to central energy management software over Ethernet networks.

• Water and Wastewater Facilities: Connecting remote pumping stations and treatment sensors via standardized industrial communications to main control rooms.

• Machine Building: Enabling modular machinery components to communicate seamlessly over fast fieldbus networks with unified control systems.
