Phoenix 2907719 Analog Output Modules

Brand： PHOENIX Model number：2907719

Country of origin:Germany Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

PHOENIX CONTACT offers a versatile lineup of analog output modules within its key automation ranges, including the Inline, Axioline F, and Axioline E series. These modules function as high-resolution digital-to-analog converters that receive register values from the bus coupler or central controller across industrial networks such as PROFINET, EtherNet/IP, PROFIBUS, or EtherCAT. The modules feature integrated short-circuit protection, channel-level isolation, and advanced diagnostic monitoring to detect wire breaks or short circuits in real time. Their modular design allows engineers to build highly customized, expandable remote I/O nodes that ensure high Signal-to-Noise Ratio (SNR) and exceptional signal fidelity even in harsh electromagnetic environments.

Product Parameters

Output Signal Types: Configurable standard signals including 0 to 10 V, ±10 V, 0 to 5 V, ±5 V, 0 to 20 mA, and 4 to 20 mA.
Number of Channels: Variations available in 2-channel, 4-channel, or 8-channel configurations per module.
Resolution: High-precision digital-to-analog conversion typically offering 12-bit, 16-bit, or higher precision.
Conversion Time: Rapid update rates ranging from under 1 ms to 5 ms depending on channel configuration and active filtering.
Transmission Error: Low basic error limit, typically below ±0.1% of the full-scale output value at ambient temperature.
Load Impedance: Voltage outputs support load resistance greater than 1 kΩ; current outputs support load impedance up to 500 Ω or 600 Ω.
Galvanic Isolation: High electrical isolation between backplane logic, auxiliary power supply, and output channels, typically rated at 500 VAC to 1500 VAC.
Power Supply: Powered via standard 24 VDC bus lines or direct local supply terminals.
Operating Temperature Range: Standard operational temperatures from -25°C to 60°C, with extended ranges up to -40°C to 70°C for extreme environmental variants.
Protection Class: Standard IP20 ratings for cabinet installation, or IP67/IP69K for field-mounted block I/O variants.

Product Advantages

A key strength of PHOENIX CONTACT Analog Output Modules is their high immune fidelity and precision, ensuring accurate positioning of actuators without signal drift caused by industrial noise.

The push-in connection technology significantly speeds up wiring processes and eliminates the need for tool-based installation, reducing overall panel assembly costs and installation errors.

Advanced onboard diagnostics provide early detection of wire breaks, output overloads, or module power failures, which reduces system downtime and simplifies field troubleshooting.

The extremely compact width of these modules saves valuable DIN rail space in control cabinets while maintaining high channel density and optimal thermal management.

Important Considerations and Precautions

When installing and wiring analog output channels, shielded twisted-pair cables must be used, with shield grounding applied according to electromagnetic compatibility guidelines to prevent external interference.

Operators must carefully check that the software channel parameterization matches the connected field device's input range to avoid driving incorrect voltages or currents that could damage connected equipment.

Care must be taken not to exceed the maximum allowable load resistance on current loop outputs, as excessive impedance will cause signal saturation and inaccurate control output.

Always ensure the module operates within its specified power supply range, and verify that total cabinet heat dissipation is managed if multiple analog modules are placed adjacent to one another.

Hot-swapping or replacing modules should only be conducted when supported by the specific base terminal system and system safety protocols to prevent unexpected actuator movement.

Product Applications

PHOENIX CONTACT Analog Output Modules are widely implemented across various continuous process and discrete manufacturing industries.

Process Valve Control: Regulating pneumatic or motorized control valves, dampers, and positioners in chemical plants, water treatment facilities, and oil refineries.
Drive Speed Regulation: Providing precise speed reference signals to variable frequency drives and servo systems in material handling, conveyors, and packaging lines.
Heating and Thermal Systems: Controlling solid-state relays or power controllers to modulate heating element outputs in industrial furnaces and plastic injection molding machines.
Building and Environmental Automation: Driving modulating actuators for HVAC dampers, chilled water valves, and fan speed controllers in large-scale facility control systems.
Signal Generation and Testing: Acting as calibrated current or voltage sources in automated test equipment, bench testing, and simulation systems.
