2904602 QUINT4-PS/1AC/24DC/20 PHOENIX

Phoenix 2904602 QUINT4-PS/1AC/24DC/20 controller module

Brand： PHOENIX Model number：2904602 QUINT4-PS/1AC/24DC/20

Country of origin:Germany Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

Phoenix Contact controller modules act as the central intelligence in distributed or centralized control topologies. Operating on robust embedded real-time hardware, these modules execute complex control programs, manage deterministic I/O tasks, and coordinate field communication over protocols such as PROFINET, Modbus TCP, EtherNet/IP, and CANopen. Advanced series like the PLCnext Control family feature an open Linux-based architecture, allowing engineers to combine traditional IEC 61131-3 PLC programming with high-level languages like C++, C#, and Python, alongside open-source software tools. The modular construction allows users to seamlessly clip expansion I/O units, bus couplers, and specialized functional modules onto the main controller without requiring complex wiring.

Product Parameters

Processor Architecture: High-performance ARM Cortex or x86 processors depending on the series and processing speed requirements.
Operating System: Embedded Linux or proprietary real-time operating system (RTOS) ensuring deterministic execution.
Programming Languages: IEC 61131-3 standard languages (LD, FBD, ST, IL, SFC) alongside high-level programming support for C++, C#, and Python via software environments like PLCnext Engineer.
Communication Interfaces: Dual Ethernet ports (RJ45) supporting integrated switches, serial interfaces (RS-232, RS-485), and optional USB ports for configuration and memory extensions.
Fieldbus and Network Protocols: Integrated support for PROFINET RT/IRT, Modbus TCP, EtherNet/IP, OPC UA server/client, and MQTT for cloud connectivity.
Input Voltage: Standard 24 VDC industrial power supply input with permissible range variations from 19.2 VDC to 30 VDC.
Memory Capacity: High-capacity onboard Flash storage for program memory and system files, with dedicated RAM for program execution, expandable via SD card options.
Operating Temperature: Extended industrial range typically from -25°C to 60°C (-13°F to 140°F).
Vibration and Shock Resistance: Built to IEC 60068 standards for high resistance to mechanical stress in heavy industrial environments.
Status Indicators: Diagnostics LEDs on the front panel providing visual status for power, module state, fieldbus communication, and fault conditions.

Product Advantages

Phoenix Contact controller modules feature exceptional flexibility and future-proof design, particularly through open ecosystem integration that bridges traditional automation with modern industrial IoT systems.

The space-saving modular designs reduce control cabinet footprints and lower installation costs through tool-free push-in wiring connection technology.

Integrated cybersecurity protocols, such as secure network encryption and user authentication mechanisms, safeguard automation networks against unauthorized access and cyber threats.

Direct support for standard IT protocols and cloud services allows easy data extraction, predictive maintenance implementation, and remote telemetry integration without needing extra external gateway hardware.

Efficient processing power and fast backplane bus communication enable rapid cycle times, high data throughput, and precise synchronicity across automated production lines.

Important Considerations and Precautions

Ensure the external 24 VDC power supply meets industrial noise suppression standards and remains strictly within the specified voltage limits to prevent unexpected processor resets.

Grounding and shielding precautions must be rigorously followed, particularly for Ethernet cables and communication lines, to avoid electromagnetic interference in high-voltage environments.

When programming in high-level languages like C++ alongside traditional PLC code, memory management and execution timing must be strictly structured to maintain deterministic system operation.

Always back up project files and configuration parameters to external memory media before updating firmware on the controller module.

Electrostatic discharge precautions must be observed during installation, handling, and module swap procedures to prevent damage to internal microprocessors and delicate electronic circuitry.

Product Applications

Phoenix Contact controller modules are deployed globally across diverse industrial environments demanding precise control and high network availability.

Factory Automation: Controlling high-speed assembly equipment, robotic work cells, material handling systems, and packaging machinery.
Process Industry and Water Management: Managing pumping stations, wastewater treatment plants, chemical distribution systems, and environmental monitoring networks.
Building Automation and Infrastructure: Interfacing lighting, HVAC systems, energy management equipment, and traffic management control systems.
Renewable Energy Systems: Regulating wind turbine generator parameters, tracking solar panel arrays, and managing battery energy storage system (BESS) operations.
Machine Building (OEM): Serving as compact, high-efficiency main controllers for custom standalone machinery requiring integrated safety and cloud Connectivity.
