2900299 PHOENIX

Phoenix Contact processor modules are designed as high-performance controllers capable of running real-time deterministic control tasks alongside open-source Linux operating environments. The module manages data exchange across local backplane buses, industrial Ethernet networks, and cloud platforms. By integrating standard programming languages according to IEC 61131-3 with high-level programming capabilities like C++, Python, and C#, these processors allow automation engineers and software developers to collaborate on a single hardware platform. The module functions as the intelligent core of the control cabinet, processing field signals, running complex algorithms, and maintaining reliable network communications.

Product Parameters

• Processor Architecture: Multi-core ARM Cortex or Intel x86 industrial processor depending on model class.

• Operating System: Real-time dual-kernel Linux operating system.

• Main Memory: 512 MB to 2 GB DDR3 or DDR4 RAM.

• Program and Data Storage: Onboard eMMC flash memory supplemented by external SD card slots for logging and program backup.

• Local Bus Expansion: Integrated high-speed local bus interface supporting up to 63 Inline or Axioline I/O modules.

• Ethernet Interfaces: Dual independent 10/100/1000 Mbps RJ45 Ethernet ports supporting switched or distinct network configurations.

• Supported Fieldbus Protocols: PROFINET Controller/Device, Modbus TCP, EtherNet/IP, and OPC UA server/client.

• Supply Voltage: 24 VDC nominal operating voltage range with reverse polarity protection.

• Operating Temperature Range: -25°C to 60°C (-13°F to 140°F) for standard industrial enclosure mounting.

• Degree of Protection: IP20 rating for installation inside control cabinets.

Product Advantages

The primary advantage of the Phoenix Contact processor module is its open ecosystem design, allowing seamless integration of open-source software libraries, containerized applications like Docker, and traditional PLC programming.

Its robust hardware design features high resistance to electromagnetic interference and extreme temperatures, ensuring maximum uptime in demanding industrial environments.

Dual independent Ethernet interfaces enable clean network separation between local machine networks and higher-level enterprise or cloud infrastructures.

The high-speed local bus connection ensures microsecond-level synchronization between the processor module and connected I/O slice modules, delivering high precision for motion control and fast processing tasks.

Important Considerations and Precautions

When installing and programming the processor module, ensure proper thermal management inside the control cabinet to prevent ambient temperatures from exceeding the maximum operating limit.

A clean, stable 24 VDC power supply with adequate current capacity must be used to prevent unexpected CPU resets during heavy processing loads or field bus traffic surges.

Standard cybersecurity practices must be followed, including changing default admin passwords, closing unused communication ports, and keeping system firmware updated to protect against unauthorized access.

Always insert or remove expansion I/O modules only when the system power is completely isolated to protect the internal bus interface pins from electrical damage.

Electrostatic discharge precautions must be strictly observed during installation, wiring, and SD card handling to prevent invisible damage to sensitive semiconductor components.

Product Applications

Phoenix Contact processor modules are applied across diverse automation sectors requiring reliable control and data communication.

• Factory Automation and Machine Building: Controlling complex machinery, assembly lines, packaging systems, and robotic cells requiring fast cycle times and precise synchronization.

• Renewable Energy and Smart Grid: Managing solar PV inverters, wind turbine control sub-systems, and energy storage management units that rely on remote data monitoring via OPC UA.

• Water and Wastewater Treatment: Operating distributed pumping stations, filtration units, and dosing systems using remote communication protocols over long distances.

• Building Infrastructure and HVAC: Centralizing control of climate units, lighting arrays, and energy management systems across commercial facilities.

• Process Automation: Interfacing with distributed process I/O racks, field instruments, and analytical units in chemical, food, and beverage production plants.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！
