2750057 PHOENIX

Phoenix 2750057 Memory Board, Dynamic

Brand： PHOENIX Model number：2750057

Country of origin:Germany Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

The Phoenix Dynamic Memory Board functions as an essential volatile memory resource within an industrial control system or embedded computing rack. Utilizing dynamic random-access memory (DRAM) technology, the board provides high-density memory storage in a compact circuit board layout. It interfaces directly with the host controller bus, enabling high-bandwidth data transfers required for executing large control programs, running real-time operating systems, and buffering continuous streams of sensor data. The module is engineered with industrial-grade components to maintain high operational reliability under continuous exposure to heat, electrical noise, and physical vibration commonly found in factory environments.

Product Parameters

Memory Type: High-speed Dynamic Random-Access Memory (DRAM).
Memory Capacity: High-density capacity options tailored for industrial embedded controllers and real-time processing units.
Bus Interface: Standardized edge connector for high-speed multi-pin bus integration with host control backplanes.
Access Speed: Ultra-low latency read/write access cycles optimized for real-time control applications.
Operating Voltage: Standard low-power supply required directly from the rack backplane or system mainboard.
Error Correction: Integrated hardware Error-Correcting Code (ECC) functionality to automatically detect and correct single-bit memory errors.
Operating Temperature Range: Industrial standard from 0°C to 55°C (32°F to 131°F) with extended temperature options available.
Storage Temperature Range: -40°C to 85°C (-40°F to 185°F).
Relative Humidity: 5% to 95% non-condensing operational tolerance.
Form Factor: Compact printed circuit board with protective industrial coating and mounting guides.

Product Advantages

A key advantage of the Phoenix Dynamic Memory Board is its high data throughput capability, which eliminates memory bottlenecks during intensive real-time control and data processing tasks.

The inclusion of advanced Error-Correcting Code (ECC) technology substantially improves system reliability by preventing bit-flip errors that could otherwise lead to unexpected system crashes or corrupted control states.

Its ruggedized industrial construction ensures stable performance in harsh operating environments where standard commercial memory modules would fail due to thermal stress or vibration.

Furthermore, its plug-and-play architecture allows simple installation and seamless system expansion without requiring extensive hardware reconfiguration.

Important Considerations and Precautions

Because dynamic memory is volatile, all stored data will be lost when power to the system is removed, making it necessary to pair the board with non-volatile flash or battery-backed storage if permanent data retention is required.

Electrostatic discharge (ESD) precautions must be strictly followed during handling, transport, and installation; technicians should use grounded wrist straps to prevent damaging sensitive semiconductor components.

Modules should only be inserted or removed when the main system power supply is completely switched off to prevent physical or electrical damage to the backplane edge connector.

Adequate cabinet ventilation or forced-air cooling must be ensured to maintain ambient temperatures within the specified operating limits and prevent thermal throttling or memory degradation.

Inspect the gold contacts on the edge connector periodically to ensure they remain clean and free from oxidation or airborne contamination.

Product Applications

The Phoenix Dynamic Memory Board is broadly implemented across automated industrial environments where high-speed, reliable data processing is critical.

Real-Time Controller Memory Expansion: Expanding the available working RAM for complex programmable logic controllers (PLCs) and industrial computing platforms.
Data Buffering and Logging Systems: Providing temporary high-speed buffer memory for high-frequency data acquisition from industrial sensors and vision systems.
Motion Control and Robotics: Supplying real-time memory resources necessary to execute complex trajectory planning and multi-axis robotics motion algorithms.
Industrial Image and Vision Processing: Storing intermediate frame data during real-time automated optical inspection and quality control tasks.
Process Automation and SCADA Systems: Handling rapid data transfers and dynamic process variable management in large-scale distributed control systems (DCS).
