2688459 PHOENIX

Phoenix Contact PCB products encompass a comprehensive range of connection technologies, including screw, push-in, and spring-cage connection systems, as well as electronic enclosure systems designed to house custom circuit boards. The PCB terminal blocks and pluggable connectors are engineered to deliver low contact resistance and high vibration resistance across high-density layouts. Manufactured with high-grade insulating materials and durable copper alloy contacts, these products accommodate automated assembly processes such as surface-mount technology (SMT), through-hole reflow (THR), and wave soldering. They allow system integrators to establish clean, modular, and maintainable wiring connections between external field wiring and internal PCB circuitry.

Product Parameters

• Conductor Cross Sections: Supports wide wire ranges from small signal conductors (26 AWG) up to heavy-duty power conductors (4 AWG or higher).

• Rated Voltage Range: Configurable options ranging from low-voltage signal levels (up to 160 V) to industrial high-power standards (up to 1000 V IEC / 600 V UL).

• Nominal Current Capacity: Options covering sensitive signal lines (8 A) up to heavy power distribution (over 125 A).

• Pitch Sizes: Standard contact spacing options including 2.5 mm, 3.5 mm, 3.81 mm, 5.0 mm, 5.08 mm, 7.5 mm, and 15 mm.

• Connection Methods: Screw connection with tension sleeve, Push-in spring connection, Spring-cage connection, and Bolt connection.

• Insulation Material: High-performance Polyamide (PA) or Liquid Crystal Polymer (LCP) with UL 94 V-0 flammability rating.

• Soldering Compatibility: Designed for standard Wave Soldering, Through-Hole Reflow (THR), and Surface Mount Technology (SMT).

• Operating Temperature Range: Typically -40°C to 105°C, with extended thermal stability models available for high-temperature environments.

• Protection Standards: Enclosure and connector options offering ratings from IP20 up to IP67/IP68 depending on the application layout.

Product Advantages

A key advantage of Phoenix Contact PCB solutions is the high reliability of their connection mechanisms, which maintain consistent contact pressure over long operational lifespans and resist loosening due to thermal expansion or mechanical vibration.

The integration of Push-in connection technology significantly reduces wiring time during field installation by allowing tool-free direct insertion of solid or ferruled wires.

Their compact designs maximize space savings on the circuit board, enabling higher component density in increasingly miniaturized industrial devices.

In addition, high thermal resistance materials ensure seamless integration into automated SMT and THR assembly lines, lowering production costs and improving manufacturing consistency.

Important Considerations and Precautions

When selecting and applying Phoenix Contact PCB components, designers must carefully align the nominal pitch and creeping/clearance distances with the specific voltage requirements of the operating environment to prevent electrical arcing or dielectric breakdown.

Proper torque specifications must be strictly observed for screw-type terminal blocks during installation to prevent thread damage or loose conductor retention.

During reflow soldering processes, recommended thermal profiles must be followed to avoid melting or warping non-reflow-rated housing plastics.

When routing heavy currents through PCB terminal blocks, adequate copper trace width and weight on the circuit board are essential to prevent excessive thermal buildup near the solder pins.

Always ensure power is completely disconnected before inserting or removing pluggable PCB connectors to prevent electrical arcing and pin deterioration.

Product Applications

Phoenix Contact PCB components and housing solutions are utilized across a wide variety of advanced industrial and commercial electronics applications.

• Industrial Automation and PLC Modules: Serving as input/output (I/O) signal and power terminals for programmable logic controllers, remote I/O devices, and distributed control systems.

• Power Supplies and Inverters: Interfacing main grid power, DC output distribution, and control signals in industrial power supplies, uninterruptible power supply (UPS) systems, and solar power inverters.

• Drive Technology and Motion Control: Connecting power and feedback lines for frequency converters, servo drives, and motor controllers operating under continuous vibration.

• Process Instrumentation and Sensor Systems: Transmitting sensitive analog and digital signals from temperature transmitters, pressure sensors, and flowmeters to central monitoring systems.

• Building Automation and Energy Management: Powering and controlling HVAC controllers, smart energy meters, lighting control systems, and security monitoring modules.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！
