CP6320.400 RITTAL

CP6320.400 Rittal Programmable controller

Brand：Rittal Model number：CP6320.400

Country of origin: Germany Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

The Rittal CP 6320.400 is a key component within the Rittal CP support arm system for mounting control enclosures and operating panels. Specifically, it is a coupler that connects the different segments of the support arm structure, allowing for flexible routing of cables and adjustment of the control panel's position.

Product Specifications

Product Type: Coupler (for support arm system)
Model Number: CP 6320.400
Range: CP 60/120/180
Material: Die-cast aluminum
Surface Finish: Powder-coated
Color: RAL 7035 (Light Gray)
Load Capacity: Max. $180 \text{ N}$ (assuming static, evenly distributed load; actual load depends on the entire arm configuration)
Protection Category: IP 54 (Provides limited ingress protection against dust and protection against splashing water)
Rotation/Adjustment: Allows for adjustable angle between the support arm segments.
Compatibility: Designed to fit support arm profiles within the Rittal CP range, typically connecting an elbow or intermediate piece to a horizontal arm or mounting profile.
Weight: Approximately $1.2 \text{ kg}$

Product Advantages

High Stability and Load-Bearing Capacity: Constructed from robust die-cast aluminum, ensuring excellent stability and reliable support for heavy control enclosures and HMI panels.
Aesthetic Design: The smooth, powder-coated finish in RAL 7035 integrates well into modern industrial environments and matches Rittal enclosures.
Internal Cable Management: The hollow design allows for protected and invisible routing of connection cables and pneumatic hoses through the support arm system, contributing to a tidy and safe workspace.
IP 54 Protection: The coupler provides a degree of protection against dust and splashing water, making it suitable for many industrial applications.
Modular and Flexible: As part of the Rittal CP system, it enables quick assembly and simple adjustment of the control panel position for optimal ergonomics.

Important Considerations (Precautions)

Load Limits: Never exceed the maximum specified static load of $180 \text{ N}$ . The overall load-bearing capacity of the entire arm system must be calculated and confirmed based on the length of the arm segments, the weight of the control box, and the configuration.
Tightening Torque: Ensure all connection screws are tightened to the torque specified in the Rittal assembly instructions. Improper torque can compromise the system's stability and load capacity.
Cable Strain Relief: Implement proper cable strain relief at the entry and exit points of the coupler and the control enclosure to prevent damage to the internal wiring.
Enclosure Suitability: The IP 54 rating applies to the coupler itself. The total protection rating of the entire assembly depends on the ratings of all connected components (e.g., the control enclosure and interfaces).
Grounding: Ensure that the support arm system and the connected control enclosure are properly grounded according to local electrical safety standards.

Product Applications

The Rittal CP 6320.400 Coupler is a standard component used in machine construction and industrial automation wherever human-machine interfaces (HMI) or operator control panels need to be mounted ergonomically and securely.

Typical applications include:

Machine Operating Stations: Mounting HMI panels, monitors, or keyboards on production machines, CNC equipment, and robotic cells.
Process Control: Supporting operator terminals in control rooms or near equipment in processing plants.
Assembly Lines: Providing an adjustable mounting solution for visualization and control units.
Industrial IT Applications: Securing display units and thin clients in rugged industrial settings where a stable, flexible viewing angle is required.
