TC810N1013 HONEYWELL

HONEYWELL TC810N1013 Communication Processor

Brand：HONEYWELL Model number：TC810N1013

Country of origin: United States Product weight：0.4kg

HS code：8517623990

Product Details：

Product Dimensions：

A Honeywell Communication Processor (CP) is an intelligent, high-speed module designed to manage data flow and network connectivity within a control system architecture. Its primary purpose is to offload the heavy burden of network communication from the main controller's processor, ensuring that the controller can focus on its primary task of executing control logic. This improves system performance, reliability, and security. CPs are essential for connecting a system's various components over industrial networks and enabling communication with higher-level systems like Human-Machine Interfaces (HMIs) and Supervisory Control and Data Acquisition (SCADA) systems.

Functionality: A CP handles all aspects of network communication, including protocol management, data formatting, message routing, and security. It acts as a gateway or a node on the network, ensuring that data is transferred efficiently and without loss. CPs often manage communication with multiple I/O racks, other controllers, and external devices.
Types: Honeywell provides different CPs tailored to specific control platforms and network types. Examples include processors for their Experion Process Knowledge System (PKS) and various legacy systems. They are typically categorized by their network protocol support (e.g., Ethernet, Modbus) and their processing power.

Product Parameters

Specific parameters for a Honeywell CP will depend on the model, but here are some common specifications:

Processor Type: A dedicated microprocessor designed for network processing.
Network Interfaces: Number and type of communication ports (e.g., RJ45 Ethernet ports, fiber optic ports).
Communication Protocols: Supported protocols such as TCP/IP, Ethernet/IP, Modbus TCP, and proprietary Honeywell protocols.
Data Transfer Rate: The speed at which data can be transmitted and received (e.g., 10/100 Mbps or 1 Gbps).
Memory: Internal RAM and flash memory for buffering data and storing firmware.
Power Consumption: The amount of power the module requires.
Operating Temperature: The range of ambient temperatures in which the module can operate reliably.
Mounting: Typically rack-mounted within a control system chassis or cabinet.

Product Advantages

Enhanced Performance: By offloading communication tasks, CPs free up the main controller to execute control logic more quickly and efficiently, leading to faster response times.
Scalability: They enable the expansion of a control system by supporting a large number of connected devices and I/O points over a single network.
Improved Reliability: Dedicated communication processors reduce the risk of a single point of failure and ensure consistent data exchange, which is critical for continuous processes.
Robust Security: CPs often include built-in security features to protect the control network from unauthorized access and cyber threats.
Interoperability: They facilitate seamless communication between a Honeywell system and devices from other vendors that support standard industrial protocols.
Simplified Architecture: They streamline the network topology, making it easier to manage and troubleshoot large-scale automation systems.

Important Considerations

System Compatibility: Ensure the specific communication processor is compatible with your existing Honeywell control platform (e.g., Experion PKS) and the modules it needs to communicate with.
Network Design: Proper network architecture, including IP addressing, subnetting, and redundancy, is essential for optimal performance and reliability. Consult Honeywell's documentation for best practices.
Security: Always configure the CP with strong passwords, network segmentation, and other cybersecurity measures to protect your industrial control system.
Firmware Updates: Keep the firmware up to date to ensure the latest features, bug fixes, and security patches are applied.
Environmental Conditions: Install the module within the specified temperature and humidity ranges to prevent premature failure.

Product Applications

Honeywell Communication Processors are fundamental components in a wide range of industrial and commercial applications:

Process Control: In industries like oil and gas, chemicals, and pharmaceuticals, they manage the vast flow of data between controllers, field instruments, and control room systems.
Power Generation: They enable the monitoring and control of power plant operations, including turbines, boilers, and electrical distribution.
Manufacturing: Used in large manufacturing facilities to connect PLCs, robots, and other machinery to a central supervisory system for production monitoring and control.
Building Automation: In large commercial or institutional buildings, they help integrate and manage HVAC systems, lighting, and security.
Water and Wastewater: They facilitate communication between remote pumping stations and a central control room for monitoring and automation.

TC804B HONEYWELL

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
