HONEYWELL MIDAS-E-SHX I / O module

Brand：HONEYWELL Model number：MIDAS-E-SHX

Country of origin: United States Product weight：0.4kg

HS code：8517623990

Product Details：

Product Dimensions：

A Honeywell I/O module is a core element of a control system rack, designed to reliably connect sensors and actuators to the main controller. It converts real-world physical signals into digital data for the controller and vice versa, enabling the automation of complex processes.

Functionality: I/O modules perform signal conditioning, electrical isolation, and conversion. They take raw signals from field instruments (like thermocouples, pressure transmitters, switches) and translate them into a stable, noise-free format the controller's processor can understand. Conversely, they take control commands and turn them into the necessary voltage or current to operate actuators (like motor valves or pump starters).
Types: Honeywell offers an extensive range of modules specific to their platforms (e.g., Experion PKS, PlantScape, Safety Manager), including:

Digital Input Modules (DI): Handle binary on/off signals from switches, pushbuttons, and proximity sensors.
Digital Output Modules (DO): Send binary signals to control solenoids, relays, contactors, and indicator lights.
Analog Input Modules (AI): Measure continuous variables like temperature, pressure, flow, and level using signals like 4-20mA or 0-10V. Often support HART protocol for enhanced smart device diagnostics.
Analog Output Modules (AO): Output continuous signals (e.g., 4-20mA, 0-10V) to control variable speed drives, modulatory valves, and positioners.
Specialty Modules: Including high-speed counter modules, pulse width modulation (PWM) modules, and direct thermocouple/RTD input modules that handle linearization and cold-junction compensation internally.

Architecture: Many Honeywell systems utilize redundant I/O capabilities and feature hot-swappable designs, allowing modules to be replaced without powering down the system, a critical feature for continuous process industries. Their Universal Channel or Triconex safety modules represent high-end, fault-tolerant offerings.

Product Parameters

Specific parameters depend on the platform and module model:

Voltage/Current: Digital modules range from 24V DC to 230V AC. Analog signals are typically 4-20mA, 0-20mA, or 0-10V DC.
Channel Density: Typically 8, 16, or 32 channels per module, varying by physical size and function.
Resolution (Analog): High resolution is standard, often 16-bit or better for precise measurement and control.
Isolation: High-level galvanic isolation (channel-to-channel or group-to-group) is standard to prevent noise and damage.
Update Rate: The speed at which the module can sample inputs or update outputs, critical for fast loops.
Wiring Termination: Often uses detachable terminal blocks or specialized field termination assemblies (FTAs) for simplified wiring and pre-cabling.
Operating Temperature: Designed for harsh industrial environments, meeting wide operating temperature ranges.
Certifications: Compliance with critical industry standards, including ATEX/IECEx for hazardous areas, SIL (Safety Integrity Level) ratings (e.g., SIL 3) for safety modules, and various global electrical/EMI standards.

Product Advantages

High Reliability and Uptime: Designed for mission-critical applications in continuous process industries, often featuring high Mean Time Between Failures (MTBF) and redundancy options.
Advanced Diagnostics: Built-in diagnostics monitor wire faults, short circuits, and open circuits, providing early warnings and facilitating faster maintenance.
Fault Tolerance: Modules designed for safety and critical control often employ triple modular redundancy (TMR) to ensure continuous operation even after a component failure.
Hot Swappability: Allows for maintenance and replacement of failed modules without interrupting the running process, minimizing costly downtime.
Seamless Integration: Designed to integrate natively with Honeywell's DCS and control platforms, simplifying configuration and data exchange.
HART Support: Many analog modules support HART communication, allowing the control system to receive and utilize diagnostic data from smart field devices.

Important Considerations

Platform Specificity: Honeywell I/O modules are typically specific to a control platform (e.g., Experion PKS vs. Safety Manager). Ensure the module is compatible with the existing controller and chassis.
Wiring Philosophy: Understand the system's wiring philosophy (e.g., direct wiring to terminal blocks vs. using Field Termination Assemblies) as this dictates physical installation.
Safety System Requirements: For modules in safety-critical loops, ensure the module has the required SIL rating and is correctly configured for the safety application.
Configuration Tools: Requires use of Honeywell's proprietary engineering tools (e.g., Control Builder) for proper configuration and addressing.
Hazardous Area Compliance: Verify the module is certified and correctly installed with appropriate barriers if placed in a hazardous (classified) area.

Product Applications

Honeywell I/O modules are primarily used in large-scale, continuous, and mission-critical process control applications:

Oil and Gas: Upstream, midstream, and downstream (refineries) control for process, safety, and emergency shutdown systems.
Chemical and Petrochemical: Managing complex reactors, distillation columns, and material blending processes.
Power Generation: Controlling boiler operations, turbine speed, and auxiliary plant equipment.
Pharmaceutical and Biotech: Precise control and validation of batch processes, bioreactors, and clean utilities.
Mining and Metals: Controlling conveyors, furnaces, and material handling systems.
Pulp and Paper: Controlling continuous web processing, stock preparation, and chemical recovery.
Water and Wastewater: Managing pump stations, filtering, chemical dosing, and compliance monitoring.
