FF-SB14E064-S2 HONEYWELL

Product Dimensions：

Parameters can vary significantly depending on the specific module series (e.g., C-Series, Safety Manager). Key parameters typically include:

• Output Signal: Common options are 4-20mA, 0-20mA, 0-10VDC, and ±10VDC.

• Number of Channels: The number of individual output points per module, often 8 or 16 channels.

• Resolution: The precision of the digital-to-analog conversion, typically 12-bit or 16-bit. Higher resolution provides finer control.

• Accuracy: The tolerance of the output signal from the ideal value (e.g., ±0.1%).

• Supply Voltage: The power required to operate the module, often 24VDC.

• Redundancy Support: Some modules are designed to operate in redundant pairs for high-availability applications.

• Environmental Rating: Specifications for operating temperature, humidity, and certifications for use in hazardous areas (e.g., Class I, Division 2).

Product Advantages

• High Precision: Honeywell modules are engineered for accuracy, ensuring precise control over critical processes.

• Reliability: Designed for continuous operation in harsh industrial environments, they contribute to system uptime and stability.

• Flexibility: A variety of modules with different channel counts and output types allows for a tailored solution for various applications.

• Integration: These modules are designed to integrate seamlessly within Honeywell’s larger control systems like Experion PKS, simplifying configuration and management.

• Advanced Features: Many modules offer advanced features like HART protocol support, which allows for communication with smart field devices.

• Diagnostics: Built-in diagnostics help with troubleshooting by monitoring for open wires or other faults.

• Safety Certification: Analog output modules for safety systems (like Safety Manager) are certified to meet high Safety Integrity Level (SIL) standards, ensuring reliable operation in critical safety applications.

Important Considerations

• Compatibility: Ensure the module is compatible with your specific Honeywell controller (e.g., Experion C300, ControlEdge HC900) and the communication protocol being used.

• Application Requirements: Select a module with the correct output signal type, current/voltage range, and resolution for your specific field devices.

• Hazardous Environments: If installing in a hazardous location, verify the module has the appropriate certifications (e.g., ATEX, UL, IECEx).

• Wiring: Follow the manufacturer's wiring diagrams and best practices to ensure proper operation, including correct grounding and shielding.

• Power Supply: Provide a stable and clean power supply that meets the module's voltage and current requirements.

Product Applications

Honeywell Analog Output Modules are fundamental to a wide range of industries and applications, including:

• Process Control: Regulating fluid flow, temperature, pressure, and level in industries such as oil and gas, refining, and chemicals.

• Power Generation: Controlling fuel valves, turbine governors, and boiler feedwater pumps.

• Building Automation: Managing variable speed drives for HVAC systems and controlling lighting intensity.

• Water and Wastewater: Regulating chemical dosing pumps and controlling valve positions.

• Pharmaceuticals: Controlling the precise flow and mixing of ingredients in drug manufacturing.

• Safety Systems: In safety-critical applications, certified analog output modules are used for emergency shutdown systems and critical control loops.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！

Honeywell 51304650-100

Honeywell CC-PAIM01

Honeywell CC-PAIH01

Honeywell CC-PAOH01

Honeywell CC-TAOX01

Honeywell CC-TAIX01

Honeywell CC-TDOB01

Honeywell CC-TDIL01

Honeywell MC-TAMR04

Colour：new                                   Warranty: 12 months

Lead Time：3-day working day      Price: Please contact us

Shipping Port: Xiamen, China         Payment:T/T

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
