F76S-1 AA HONEYWELL Gate Module
Brand：HONEYWELL Model number：F76S-1 AA
Country of origin: United States Product weight：0.4kg
HS code：8517623990
Product Details：
Product Dimensions：
The Honeywell Gate Module is a critical component in fire alarm and building management systems, designed to facilitate the safe and controlled shutdown or operation of auxiliary equipment like dampers, fire doors, or HVAC systems during an emergency. It acts as an interface, receiving signals from the fire alarm control panel (FACP) and translating them into actions for external devices.
Operating Voltage: Typically draws power directly from the fire alarm loop (e.g., $24\text{V} \text{DC}$ nominal).
Current Draw: Standby current is usually very low, with a higher current draw when the relay is activated (alarm state).
Relay Type: Features a Form C (SPDT - Single-Pole Double-Throw) relay, providing both Normally Open (NO) and Normally Closed (NC) contacts. This allows flexibility in controlling various types of external equipment.
Relay Contact Ratings: The contacts are rated to handle specific voltages and currents (e.g., $2\text{A}$ at $30\text{V} \text{DC}$ or $0.5\text{A}$ at $120\text{V} \text{AC}$).
Compatibility: Designed for use with specific Honeywell intelligent or addressable fire alarm control panels (FACPs).
Addressing: The module is addressable, meaning it occupies a unique location on the Signaling Line Circuit (SLC) loop, allowing the FACP to monitor and control it individually.
Wiring: Connects to the two-wire SLC loop and requires separate wiring for the device it controls.
Operating Temperature: Engineered to function reliably across a wide temperature range, typically from $0^\circ \text{C}$ to $49^\circ \text{C}$.
Enhanced System Control: Provides precise, addressable control over critical building functions, allowing for a targeted emergency response.
Flexibility (Form C Relay): The SPDT contact configuration offers versatility, enabling the module to be used for both activation and deactivation of devices.
Ease of Installation and Commissioning: The module is typically compact and designed for easy mounting in standard electrical boxes. Rotary switches or electronic addressing simplify setup.
Supervision: As part of an addressable system, the module and its wiring are continuously supervised by the FACP, ensuring faults (like an open circuit) are detected immediately.
Reliability: Built to strict fire safety standards, ensuring dependable operation during a fire event.
Compatibility: Always verify that the module is compatible with the specific Honeywell FACP model being used.
Wiring Limits: Adhere strictly to the maximum wire gauge and length specifications for both the SLC and the controlled device wiring.
Contact Load: Never exceed the relay contact current or voltage ratings. Use an intermediate relay or contactor if the controlled device's power requirements are higher than the module's rating.
Installation Location: Install the module in a dry, protected area within the specified operating temperature range.
NFPA Compliance: Installation and testing must be performed by qualified personnel and comply with all applicable local codes and standards, such as NFPA 72.
The Gate Module is essential for managing ancillary life safety functions within a building, including:
HVAC System Shutdown: De-energizing air handlers or shutting down ventilation to prevent the spread of smoke and fire through ductwork.
Fire/Smoke Damper Control: Opening or closing motorized fire and smoke dampers to isolate fire zones and control smoke migration.
Door Holder Release: Releasing the magnetic holders for fire-rated doors, allowing them to close and compartmentalize the building.
Elevator Recall: Sending a signal to the elevator control system to initiate emergency recall to a designated floor.
Stairwell Pressurization: Activating fans to pressurize stairwells, keeping them smoke-free for evacuation.
Auxiliary Notification: Activating secondary signaling devices, such as voice evacuation systems or specialized strobe lights.
