DC120L-1-1-0-0-1-1-0-0 HONEYWELL

DC120L-1-1-0-0-1-1-0-0 HONEYWELL Analog Output Modules

Brand：HONEYWELL Model number：DC120L-1-1-0-0-1-1-0-0

Country of origin: United States Product weight：0.4kg

HS code：8517623990

Product Details：

Product Dimensions：

Honeywell Analog Output Modules are essential components in industrial control and automation systems, serving as the interface between the digital controller (PLC, DCS) and field devices that require an analog signal for operation, such as control valves, actuators, and transmitters. These modules convert the digital control value from the processor into a smooth, continuous analog signal, typically a current (e.g., 4-20mA) or a voltage (e.g., 0-10V or $\pm10V$ ), to accurately manipulate process variables. Many modern Honeywell output modules, such as those in the ControlEdge or Experion PKS platforms, offer high channel density, robust diagnostics, and support for advanced communication protocols like HART, enabling enhanced device management. A key feature in some high-reliability series is the inclusion of fail-safe functionality, ensuring that outputs revert to a predetermined safe state in the event of a fault or loss of communication.

Product Parameters (General/Representative)

While specific parameters vary significantly by product series (e.g., Series C, ControlEdge HC900, FSC), here are representative specifications:

Output Channels: Typically 4, 8, or 16 channels per module.
Output Signal Types: Common outputs include 4-20mA, 0-20mA, 0-10V, and $\pm10V$ .
Resolution: Often 12-bit or 16-bit, which determines the precision of the analog signal.
Isolation: Galvanic isolation is frequently provided, either channel-to-channel, channel-to-ground, or group-to-ground, to prevent interference and maintain signal integrity.
HART Support: Many analog output modules support the HART (Highway Addressable Remote Transducer) protocol for simultaneous digital communication over the analog wiring.
Operating Temperature: Designed to operate in harsh industrial environments, with ranges often extending from $-40^\circ C$ to $+70^\circ C$ or higher.
Fail-Safe/Safe-State: User-configurable safe values or states for outputs upon detection of a system or communication failure.

Product Advantages

Honeywell Analog Output Modules offer several advantages that contribute to reliable and efficient process control:

High Reliability and Robustness: Built for harsh industrial environments, often featuring durable construction and redundancy options to ensure continuous, reliable performance.
Enhanced Diagnostics: Integrated diagnostics for features like open wire detection and short-circuit protection help quickly identify and troubleshoot wiring faults, minimizing downtime.
High Density and Space Savings: Modern designs often maximize channel density, allowing more outputs in a smaller physical footprint, which saves valuable cabinet space and reduces installation costs.
Fail-Safe Operation: Critical in safety-instrumented systems, the built-in fail-safe capability ensures the process moves to a safe, controlled state if the controller or module fails.
HART Communication: Support for HART allows for richer, two-way communication with field devices, facilitating remote configuration, calibration, and diagnostic monitoring without interrupting the analog signal.

Important Considerations (Precautions)

To ensure optimal performance and safety, users should adhere to the following precautions:

Follow Installation Guidelines: Always disconnect power before installing or replacing modules to avoid electric shock and equipment damage. Observe proper grounding and wiring practices as specified in the product manual.
Observe ESD Precautions: Electronic modules are sensitive to Electrostatic Discharge (ESD). Handle modules only at approved workstations and follow standard ESD protective measures.
Verify Output Load Specifications: Ensure that the field device's impedance and current draw are within the specified limits of the analog output channel to prevent damage and guarantee accuracy.
Configure Safe-State Values: Before commissioning, carefully configure the desired fail-safe values for all output channels. This is crucial for maintaining process safety during controller or communication faults.
Use Appropriate Cabling: Use the recommended cable types, often shielded twisted pair, to minimize electrical noise and interference, thereby maintaining signal integrity and accuracy.

00780-A-0100 HONEYWELL

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
