CC-PAIH02 HONEYWELL

HONEYWELL CC-PAIH02 Analog Output Modules

Brand：HONEYWELL Model number：CC-PAIH02

Country of origin: United States Product weight：0.4kg

HS code：8517623990

Product Details：

Product Dimensions：

Honeywell Analog Output Modules are key components in industrial and building automation systems, serving as the bridge between a digital controller and analog field devices. They take a digital value from a controller and convert it into a continuous analog signal, such as a voltage or current, to precisely control devices like actuators, valves, and variable speed drives. These modules are a vital part of Honeywell's diverse control platforms, including their Distributed Control Systems (DCS) like Experion PKS and various building management systems.

Product Details

Functionality: Honeywell's analog output modules perform Digital-to-Analog (D/A) conversion. They accept a digital command (e.g., a number from 0 to 4095) from the controller's central processing unit and generate a corresponding physical analog output signal (e.g., 0-10V or 4-20mA). This allows for fine-grained control over devices that don't just have simple on/off states.
Module Types: Honeywell offers a variety of analog output modules distinguished by channel count, signal type, and special features. Modules may have 4, 8, or 16 channels. Some are also equipped with HART (Highway Addressable Remote Transducer) protocol support, which allows for simultaneous analog control and digital communication over the same wiring, enabling device diagnostics and configuration.
Key Features: Modules typically offer channel-to-channel or group-to-group isolation to prevent electrical interference. They often include built-in diagnostics for open-wire detection and short-circuit protection. Many of Honeywell's modern I/O modules are hot-swappable, allowing for replacement without powering down the entire system, which is crucial for maintaining uptime in critical applications.

Product Parameters

Output Signal Types: Common outputs include 4-20mA, 0-20mA, 0-10VDC, and +/-10VDC.
Number of Channels: Varies by model, typically 4, 8, or 16 output channels per module.
Resolution: The precision of the D/A conversion, often 12-bit, 13-bit, or 16-bit, which determines the granularity of control.
Accuracy: The tolerance of the output signal, typically expressed as a percentage of full-scale value.
Channel Isolation: Specifies whether output channels are electrically isolated from each other and the system, providing protection and stability.
Communication: Some advanced modules support HART protocol for enhanced device management.
Operating Temperature: A wide industrial temperature range is common, for example, from -40°C to +70°C.
Mounting: Modules are typically designed to be mounted on a chassis or terminal block (IOTA - Input/Output Termination Assembly), which provides the field wiring connections.

Product Advantages

Precise Control: High-resolution D/A conversion allows for very accurate and fine-tuned control of industrial processes, improving product quality and system efficiency.
Robustness and Reliability: Engineered for harsh industrial environments, these modules are built to withstand high temperatures, electrical noise, and vibration, ensuring long-term stable operation.
Enhanced Diagnostics: Integrated diagnostics capabilities (e.g., open-circuit detection) simplify troubleshooting, reduce maintenance time, and improve system reliability.
Simplified Maintenance: Features like hot-swappability and a modular design allow for quick and easy replacement without disrupting the entire control system.
HART Integration: For modules with HART support, they offer the dual benefit of analog control and digital device management over the same wiring, reducing installation costs and simplifying field device configuration.
Seamless Integration: Designed to integrate flawlessly with Honeywell's control platforms, such as Experion PKS, ensuring compatibility and streamlined system setup.

Important Considerations

System Compatibility: Always verify that the specific analog output module is compatible with your controller platform (e.g., Series 8 I/O for Experion PKS or a specific building management controller).
Load Type: The module's output type (voltage or current) must match the requirements of the field device it is controlling. Incorrect pairing can damage the module or the device.
Wiring and Termination: Follow the manufacturer's specific wiring diagrams and termination instructions. Use proper shielding and grounding to prevent electrical noise from affecting signal accuracy.
Calibration: For applications requiring high accuracy, periodic calibration of the analog outputs may be necessary to ensure long-term performance.
Documentation: Always refer to the official Honeywell product datasheet and user manual for detailed specifications, wiring diagrams, and safety information.

CC-IP0101 HONEYWELL

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！

Honeywell CC-IP0101

Honeywell CC-MCAR01

Honeywell CC-PAIH02

Honeywell CC-PAIH51

Honeywell CC-PAIN01

Honeywell CC-PAIX01

Honeywell CC-PAIX02

Honeywell CC-PAOX01

Honeywell CC-PCF901

Honeywell CC-PCNTOX

Colour：new Warranty: 12 months

Lead Time：3-day working day Price: Please contact us
