80363975-150 MC-PDOY22 HONEYWELL

Product Dimensions：

A Honeywell Analog Input Module is a critical component within a distributed control system (DCS) or programmable logic controller (PLC) that serves as an interface between real-world analog signals and the digital control system. Its primary function is to measure, condition, and convert continuous electrical signals (typically voltage or current) from field devices into a digital format that the control processor can interpret and use for monitoring and control actions.

Product Parameters

Analog input modules are characterized by several key parameters:

• Input Types: Modules are designed to accept specific signal types, such as current (e.g., $4-20\text{ mA}$, $0-20\text{ mA}$) or voltage (e.g., $0-5\text{ VDC}$, $0-10\text{ VDC}$, $\pm 10\text{ VDC}$). Thermocouple (TC) and Resistance Temperature Detector (RTD) inputs are often handled by specialized analog input modules.

• Resolution: This is the smallest change in the input signal that the module can detect, typically expressed in bits (e.g., 12-bit, 16-bit). Higher resolution means greater measurement precision.

• Accuracy: Specifies the maximum error between the actual input value and the measured digital value, often expressed as a percentage of the full-scale range.

• Number of Channels: Indicates how many separate analog inputs the single module can handle (e.g., 8 channels, 16 channels). Channels can be single-ended or differential.

• Isolation: Specifies whether the individual channels, the module, or the communication bus are electrically isolated to prevent ground loops and protect against high voltages.

• Scan Rate/Conversion Time: The speed at which the module can sample and convert the analog signal to a digital value.

Product Advantages

Honeywell Analog Input Modules offer several distinct advantages in industrial automation:

• High Accuracy and Reliability: Designed for demanding industrial environments, they provide precise and consistent measurement crucial for process control.

• Robustness: Built to withstand harsh conditions, including extreme temperatures, vibration, and electrical noise, ensuring long-term operational stability.

• Seamless Integration: Designed for native compatibility with Honeywell's Experion PKS, PlantScape, or other control platforms, simplifying configuration and maintenance.

• Diagnostics: Many modules include advanced onboard diagnostics (e.g., open circuit detection, over/under range monitoring) that help pinpoint field device failures quickly, reducing downtime.

• Flexibility: A variety of module types supports a wide range of industrial sensors and transmitters, allowing for diverse application deployment.

Important Considerations (Precautions)

When installing and operating these modules, users must adhere to important precautions:

• Wiring Standards: Always use the correct shielded cables and wiring practices as specified in the product manual to minimize noise interference.

• Grounding: Ensure proper system grounding and earthing to prevent common-mode noise and maintain signal integrity.

• Power Supply: Verify that the external field device power supply meets the module's specifications and is stable.

• Configuration: Carefully configure the module's range, input type, and scaling to match the connected sensor's output and the desired engineering units in the control system.

• Environmental Limits: Do not exceed the specified operating temperature, humidity, and vibration limits to avoid hardware damage and unreliable operation.

Product Applications

Honeywell Analog Input Modules are fundamental to monitoring and controlling continuous variables across numerous industries:

• Oil and Gas: Monitoring pipeline pressure, flow rates, and tank levels.

• Chemical Processing: Measuring reactor temperature, fluid composition, and pressure in chemical reactions.

• Power Generation: Sensing boiler temperature, steam pressure, and turbine speed.

• Water and Wastewater: Tracking water flow, pH levels, and reservoir depth.

• Pharmaceuticals: Monitoring and documenting precise temperature and pressure for validation and regulatory compliance.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！

Honeywell 80363975-150 MC-PDOY22

Honeywell 2MLL-EFMT-CC

Honeywell 2MLR-E12H

Honeywell 14CE3-2

Honeywell 14CE2-2

Honeywell LDVS-5204S

Honeywell R4348-A/1026

Honeywell SPXCDDMF12

Honeywell SPXCDTMF12

Honeywell R7848A1004

Colour：new                                   Warranty: 12 months

Lead Time：3-day working day      Price: Please contact us

Shipping Port: Xiamen, China         Payment:T/T

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
