51401996-100 HONEYWELL

HONEYWELL 51401996-100 Analog Output Modules

Brand：HONEYWELL Model number：51401996-100

Country of origin: United States Product weight：0.4kg

HS code：8517623990

Product Details：

Product Dimensions：

A Honeywell Analog Output Module is an electronic card or unit that converts digital data received from a central processor into a continuous, variable electrical signal (either voltage or current). This signal is then used to control devices that require a proportional input, enabling fine-tuned adjustments rather than simple on/off control.

Functionality: These modules take a digital value (typically a 16-bit integer) from the control system and, using a Digital-to-Analog Converter (DAC), produce a corresponding analog signal. This signal is used to manipulate process variables like the speed of a motor, the position of a valve, or the power output of a heater.
Types: Honeywell provides various analog output modules to suit different applications and control platforms. They are generally categorized by the type of signal they produce:

Voltage Output Modules: These modules produce a voltage signal, commonly in a range like 0-10V DC, +/-10V DC, or 1-5V DC. They are often used to control variable speed drives, motor controllers, and instrumentation.
Current Output Modules: These modules produce a current signal, most often in the 4-20mA range. The 4-20mA standard is highly popular in industrial settings because it is less susceptible to electrical noise and can be used to detect a broken wire (a "live zero" of 4mA ensures a 0mA reading means a fault). They are used to control proportional valves, actuators, and pneumatic converters.

Key Features:

High Resolution: Typically 12-bit or 16-bit resolution, providing a large number of steps for precise control.
Isolation: Many modules feature channel-to-channel or group isolation to protect against electrical noise and ground loop issues.
Fault Detection: Built-in diagnostics can detect open circuits or short circuits on the output line.
Safe State: Configurable fail-safe or "safe state" behavior in the event of a fault or power loss.
Redundancy: Certain high-availability systems offer redundant analog output modules to ensure uninterrupted operation.

Product Parameters

The technical specifications of Honeywell's analog output modules depend on the specific product family (e.g., Experion PKS, HC900, MasterLogic). However, common parameters include:

Output Signal Range: 0-10V, +/-10V, 0-20mA, 4-20mA.
Number of Channels: Typically 4, 8, or 16 independent output channels per module.
Resolution: 12-bit, 16-bit, or higher.
Accuracy: A percentage of full scale, indicating the precision of the output signal.
Load Resistance/Impedance: The range of electrical resistance the module can drive.
Response Time: How quickly the output signal can change to a new value.
Operating Temperature: Industrial range, often from -40°C to 70°C.
Power Consumption: The amount of power the module consumes.
Certifications: Compliance with international standards such as CE, UL, and ATEX.

Product Advantages

High Precision: With high resolution, these modules enable extremely fine and accurate control of process variables, improving product quality and process efficiency.
Reliability: Built with robust components and diagnostics to ensure reliable performance in harsh industrial environments, reducing unplanned downtime.
Safety and Security: Isolation features protect the control system from electrical faults. Fail-safe configurations and fault detection add layers of operational safety.
Seamless Integration: Designed to integrate seamlessly with Honeywell's own control systems (e.g., Experion PKS) and other platforms, simplifying system design and deployment.
Reduced Noise: The use of current-based signals (4-20mA) minimizes the impact of electrical noise over long distances.
Ease of Use: Modules often feature LED indicators for status and fault diagnostics, making troubleshooting simpler for technicians.

Important Considerations

Signal Compatibility: Ensure the module's output signal type and range (e.g., 4-20mA) match the requirements of the field device you are controlling.
Power Supply: Provide a stable and clean power supply that meets the module's specifications to prevent signal instability.
Wiring Practices: Use proper shielded twisted-pair cables for analog signals to minimize electrical noise interference, especially over long cable runs. Follow best practices for grounding and cable routing.
Load Characteristics: The resistance of the load must be within the module's specified range to ensure accurate output and prevent damage.
Calibration: Analog output modules may require periodic calibration to maintain accuracy. Be aware of the calibration procedures and recommended schedules.
Software Configuration: The module's parameters, scaling, and fail-safe behavior must be correctly configured within the control system's software.

Product Applications

Honeywell Analog Output Modules are widely used across various industries for precise control applications:

Process Industries:

Chemicals and Refining: Controlling the flow of fluids, gas pressure, and reactor temperature.
Oil and Gas: Manipulating choke valves and controlling pump speed.
Pharmaceuticals: Regulating temperature in bioreactors and controlling flow rates in mixing processes.

Manufacturing and Automation:

Machine Control: Varying the speed of conveyors, fans, and pumps.
Robotics: Controlling the speed or torque of motors for precise motion control.

Building Automation:

HVAC: Controlling actuators for air dampers and regulating fluid flow in heating and cooling systems.

Power Generation:

Controlling fuel flow to a boiler or adjusting the position of a turbine throttle valve.

Water and Wastewater:

Regulating chemical dosing pumps and controlling the speed of aerators.

51401996-100 HONEYWELL

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
