51309204-175 HONEYWELL

Product Dimensions：

Honeywell Analog Input Modules come in various forms to suit different applications. They are typically modular, meaning you can easily add or replace them in a system chassis or rack. The modules are equipped with multiple channels, allowing a single module to monitor several sensors simultaneously. They are designed to accept different types of analog signals. For example, some modules are optimized for current signals (e.g., 4-20mA), which are common in industrial settings due to their noise immunity over long distances. Others are designed for voltage signals (e.g., 0-10V) or direct inputs from thermocouples and Resistance Temperature Detectors (RTDs), which measure temperature. Advanced modules feature channel-to-channel isolation, which protects against electrical noise and ground loops, ensuring a high degree of measurement accuracy. Many modules also include onboard diagnostics to monitor their health and the status of the connected sensors, which simplifies maintenance and troubleshooting.

Product Parameters

Specific parameters vary by model, but here are some typical technical specifications you'd find:

• Number of Channels: Modules are available with different channel counts, such as 8, 16, or 32 channels.

• Input Ranges: The module's capability to accept different signal types and ranges is a critical parameter. Common ranges include 4-20mA, 0-20mA, 0-10V, +/-10V, as well as direct inputs for thermocouples (J, K, T, E, N, R, S, B, C types) and RTDs (Pt100, Pt1000).

• Resolution: This indicates the precision of the analog-to-digital conversion, typically specified in bits (e.g., 12-bit, 16-bit). A higher bit resolution means more precise measurement.

• Accuracy: Specified as a percentage of the full-scale range (e.g., +/- 0.1% of full scale) and indicates how close the measurement is to the true value.

• Isolation: This parameter describes the electrical separation between channels and from the system's power supply. High galvanic isolation is essential for robust and accurate measurements in electrically noisy environments.

• Scan Rate / Update Time: This is the speed at which the module reads its inputs and updates the controller with new data. Fast scan rates are crucial for monitoring rapidly changing processes.

• Operating Temperature: Modules are built to operate reliably in a wide range of industrial temperatures, typically from -40°C to 85°C.

• Communication: Analog input modules communicate with a controller over a backplane or an industrial network, using protocols like Modbus TCP/IP, Ethernet/IP, or a proprietary bus.

Product Advantages

Honeywell Analog Input Modules offer several key advantages that make them a preferred choice for industrial applications:

• High Accuracy and Resolution: Their advanced electronics provide highly accurate and precise measurements, which is crucial for quality control and process optimization.

• Robustness and Reliability: Built to industrial standards, these modules are durable and reliable, ensuring long-term operation in harsh conditions. This minimizes the risk of system downtime.

• Simplified Installation and Maintenance: Many modules feature plug-and-play design, diagnostic LEDs, and hot-swap capability, which makes installation and maintenance faster and easier. Some modules also offer removable terminal blocks to simplify wiring.

• Flexibility: With support for a wide range of input types, a single platform can handle diverse sensor technologies without needing different module types for each.

• Enhanced Safety: Isolation features and fault detection capabilities protect the control system and its components from electrical disturbances, contributing to a safer and more stable operation.

• Seamless Integration: Designed to integrate flawlessly with Honeywell's control platforms, reducing configuration time and ensuring reliable communication.

Important Considerations

Before selecting and installing a Honeywell Analog Input Module, you should consider the following:

• Signal Compatibility: Always verify that the module's input ranges and types are compatible with your field sensors. Mismatched signals can lead to inaccurate readings or damage to the module.

• Environmental Factors: Ensure the module's operating temperature and environmental protection (e.g., IP rating) are suitable for the installation location.

• Wiring Practices: Use correct wiring techniques, including proper shielding and grounding, to minimize electrical noise and ensure signal integrity, especially for low-level signals like thermocouples.

• Power Supply: Confirm that the power supply to the module is stable and within the specified voltage and current ranges.

• Documentation: Always refer to the official Honeywell installation manual and datasheet for the specific module model. This documentation provides detailed wiring diagrams, configuration steps, and safety precautions.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！

Honeywell 51309204-175

Honeywell 51304465-100

Honeywell 51304493-250

Honeywell 51304685-150

Honeywell 51304453-150

Honeywell 51305072-600

Honeywell 51304453-100

Honeywell 51304644-125

Honeywell 51304518-150

Honeywell 51304362-300

Colour：new                                   Warranty: 12 months

Lead Time：3-day working day      Price: Please contact us

Shipping Port: Xiamen, China         Payment:T/T

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
