51304754-150 HONEYWELL

Product Dimensions：

A Honeywell Power Board is a circuit board assembly that manages and distributes electrical power within an enclosed system. Its primary functions are to convert incoming AC power to the necessary DC voltage, provide power-limited outputs for connected devices, and often include a battery charging circuit for backup power.

• Functionality: These boards act as a power hub for control systems, such as fire alarm control panels or access control systems. They ensure a stable voltage supply, protect downstream devices from faults, and often have monitoring capabilities for AC power loss or battery failure.

• Types:

• Power Supply/Charger Boards: These are the core units that convert AC to DC and provide a charging circuit for backup batteries.

• Power Distribution Boards: These boards take a single power input and split it into multiple, independently protected outputs to power various devices like sirens, locks, or sensors.

• Combined Systems: Many of Honeywell's products, especially in access control, are sold as unified systems where the power board, control boards, and battery space are all housed within a single, secure enclosure.

• Key Features:

• Supervision: Often includes supervision circuits for AC power failure and battery health, triggering a trouble signal when issues are detected.

• Protected Outputs: Outputs are typically power-limited and protected by fuses or PTCs (Positive Temperature Coefficient) to prevent damage from overcurrents.

• LED Indicators: Provide visual status of power presence, output status, and fault conditions for quick diagnostics.

• Configurability: Many boards include jumpers or dip switches to select output voltage (e.g., 12VDC or 24VDC) or other operational parameters.

• Fire Alarm Interface: Some boards have a dedicated input that can be triggered by a fire alarm panel to perform safety functions like unlocking doors (fail-safe mode).

Product Parameters

Product parameters are highly specific to the model and application but generally include:

• Input Voltage: The required input voltage, typically 120VAC or 230VAC.

• Output Voltage: The DC output voltage, commonly 12VDC or 24VDC.

• Output Current: The total continuous current the board can supply, often split across multiple outputs. For example, a board might provide 6A total, with 3A maximum per circuit.

• Number of Outputs: The number of power-limited output circuits available (e.g., 4, 8, or 16).

• Battery Support: The size and type of backup battery it can support (e.g., accommodating two 12V 12Ah batteries).

• Certifications: Compliance with safety standards such as UL (Underwriters Laboratories) or EN54 for fire safety applications.

• Physical Dimensions: The size of the board itself or the enclosure it comes in.

Product Advantages

• High Reliability: Engineered to meet stringent standards for security and life safety, ensuring dependable performance.

• Safety and Protection: Provides power-limited outputs and fault protection to safeguard both the control system and connected field devices.

• Integrated Solutions: Often part of a complete system, which simplifies installation and ensures seamless compatibility between components.

• Diagnostic Efficiency: Onboard LED indicators and diagnostic capabilities make it easy to troubleshoot issues and confirm operational status.

• Regulatory Compliance: Designed and certified to meet key industry standards, which is crucial for regulated applications like fire alarm systems.

Important Considerations

• Specific Application: You must select a power board that is specifically designed for your application (e.g., a board for a fire alarm system is different from one for access control) to ensure all features and safety requirements are met.

• Load Requirements: Ensure the board's output current and voltage ratings are sufficient for all connected devices.

• Battery Sizing: The backup battery must be correctly sized to provide power for the required standby and alarm duration, as specified by local codes and standards.

• Installation: Proper installation and wiring are critical. Follow the manufacturer's manual exactly to maintain certifications and ensure safe operation.

• Compatibility: Verify that the power board is compatible with the specific Honeywell control panels and peripherals you intend to use.

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！

Honeywell 4DP7APXPM155

Honeywell 51196653-100/HF-75805

Honeywell 51202304-100

Honeywell 51204126-915

Honeywell 51204162-175

Honeywell 51303979-100

Honeywell 51304487-100

Honeywell 51304511-100

Honeywell 51304754-150

Honeywell 620-0041C

Colour：new                                   Warranty: 12 months

Lead Time：3-day working day      Price: Please contact us

Shipping Port: Xiamen, China         Payment:T/T

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
