30735887-001 HONEYWELL

HONEYWELL 30735887-001 Gate Module

Brand：HONEYWELL Model number：30735887-001

Country of origin: United States Product weight：0.4kg

HS code：8517623990

Product Details：

Product Dimensions：

A Honeywell Gate Module is an electronic controller or expansion board that integrates a gate's physical hardware into a centralized access control and security system. It acts as a bridge, translating signals from card readers, keypads, or intercoms into commands to open or close a gate, while also monitoring the gate's status. It's not a standalone product but a key component of a larger access control ecosystem like Honeywell's WIN-PAK or Pro-Watch systems.

Functionality:

Access Control: Verifies credentials (card swipes, PIN codes) and grants or denies access.
Gate Automation: Sends signals to a gate's motor or control panel to command it to open, close, or stop.
Status Monitoring: Senses the position of the gate (open/closed) and any obstructions or tamper events.
Intercom Integration: Works with intercom systems to allow for remote visitor access.
Emergency Override: Can be configured to open the gate automatically during a fire alarm or other emergency.

Types:

Standalone Controllers: These are gate-specific controllers for a single entry point, but they still report back to a central server.
Expansion Boards: These modules connect to a main access control panel to add gate-specific I/O, such as inputs for vehicle loop detectors and outputs for gate motor controls.

Product Parameters

The parameters for a gate module are based on its role within the access control system.

Power Supply: Typically 12V or 24V DC, supplied from the main access control panel.
Inputs:

Card Reader/Keypad Inputs: For connecting card readers (often via Wiegand or RS-485).
Digital Inputs: For monitoring gate status (limit switches, open/closed sensors), safety beams, and emergency stop buttons.
Vehicle Loop Detector Inputs: For detecting vehicles approaching the gate.

Outputs:

Relay Outputs: Dry contact relays to trigger the gate's motor control panel. These can be configured for momentary or latched operation.
Auxiliary Outputs: For controlling warning lights, sirens, or status indicators.

Communication:

Data Bus: Communicates with the main access control panel via a proprietary data bus or standard protocols like RS-485 or Ethernet.
Network Compatibility: Integrates with Honeywell's WIN-PAK or Pro-Watch access control software.

Operating Environment: Designed for industrial and outdoor applications, often with a wide temperature range and in a weatherproof enclosure.

Product Advantages

Centralized Control: Allows for all gates and doors to be managed from a single, unified software platform, simplifying administration and security protocols.
Enhanced Security: Provides robust security by integrating with other security systems (e.g., video surveillance) and using advanced authentication methods.
Flexibility: Can be configured to support various gate types (swing, sliding, barrier arm) and operational logic (e.g., free exit, a two-stage closing sequence).
Reliability: Built with high-quality components to withstand continuous operation and environmental stresses.
Comprehensive Monitoring: Provides detailed logs of all gate events (access granted/denied, gate open/closed), which is critical for security audits and investigations.
Scalability: The modular design allows you to easily add more gate modules or other access points to the system as your security needs grow.

Important Considerations

System Compatibility: A gate module must be compatible with the specific Honeywell access control system and software version you are using. They are not universal.
Professional Installation: Due to the complexity and safety risks associated with gate automation, installation should always be performed by a certified and experienced professional.
Safety Features: Ensure the gate system includes all necessary safety features like photo-eye beams, loop detectors, and emergency stop buttons to prevent injury or damage.
Weather Protection: While the module itself is rugged, it must be installed in a proper weatherproof enclosure to protect it from extreme weather conditions.
Power Management: Verify that the power supply is sufficient for both the gate module and all connected devices, including readers and gate motors.
