HONEYWELL 10020/1/2 Digital Input Module

Brand：HONEYWELL Model number：10020/1/2

Country of origin: United States Product weight：0.4kg

HS code：8517623990

Product Details：

Product Dimensions：

A Honeywell digital input module is a robust electronic device that senses the state of a switch or sensor and converts it into a digital signal that the controller can understand. It's designed for reliability and accuracy in harsh industrial environments.

Functionality: The primary function is to monitor on/off signals from devices like limit switches, pushbuttons, proximity sensors, and relay contacts. It processes these signals and reports their status (true/false, on/off) to the main controller.
Design: These modules are typically designed for easy installation on a DIN rail or within a specific chassis. They often feature removable terminal blocks for simple wiring and replacement without disturbing adjacent modules.
Key Features:

Galvanic Isolation: The module provides electrical isolation between the field wiring and the control system's internal circuitry to protect against voltage spikes and noise.
LED Indicators: Each channel usually has an LED to show its status, and the module often has additional LEDs for power, communication, and fault indication.
Diagnostics: Advanced modules include built-in diagnostics to detect faults like an open wire or short circuit, improving system reliability and simplifying troubleshooting.
Communication: They communicate with the controller via a high-speed backplane or a field bus protocol like PROFIBUS or Modbus.

Product Parameters

The specific parameters for a Honeywell digital input module will vary greatly depending on the product family and model. However, here are some common specifications:

Input Voltage: Standard ratings include 24V DC, 48V DC, 120V AC, and 230V AC. Some universal modules can be configured for different voltage ranges.
Number of Channels: Modules are available with different channel densities, such as 8, 16, or 32 channels per module.
Input Type: Can be dry contact (passive switch) or wet contact (powered signal, e.g., NPN or PNP).
Response Time: The time it takes for the module to recognize and report a change in input state. This is crucial for high-speed applications and is typically in milliseconds.
Isolation: The level of electrical isolation between channels and the backplane, measured in volts (e.g., 500V or 1500V).
Operating Environment: Specifications for operating temperature (e.g., -40°C to 70°C) and relative humidity (non-condensing).
Certifications: Compliance with international safety and performance standards like CE, UL, and CSA.

Product Advantages

High Reliability: Built with robust components to ensure dependable performance and minimize downtime in industrial environments.
Ease of Use: Features like plug-and-play functionality, removable terminal blocks, and LED status indicators make installation and maintenance straightforward.
System Integration: Designed to seamlessly integrate with Honeywell's DCS and PLC platforms, providing a unified and secure control architecture.
Safety: The galvanic isolation protects the control system from electrical noise and dangerous voltages, enhancing overall system safety.
Flexibility and Scalability: The modular design allows for easy expansion or reconfiguration of the I/O system as your application's needs change.
Advanced Diagnostics: Real-time diagnostics help quickly identify and locate wiring or sensor faults, reducing troubleshooting time.

Important Considerations

Compatibility: Always ensure the digital input module is compatible with your specific Honeywell controller and I/O family (e.g., Experion PKS, Series C).
Voltage and Current: Match the module's input voltage rating and current draw to the field devices you are connecting.
Wiring: Follow the manufacturer's specific wiring diagrams and guidelines. Use proper grounding and wire sizing to prevent signal noise and ensure reliable operation.
Environmental Protection: While rugged, ensure the module is installed within its specified temperature and humidity ranges to avoid performance degradation or failure.

51402497-200 HONEYWELL

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
