PO916NG FOXBORO

PO916NG Foxboro Processor module

Brand：Foxboro Model number：PO916NG

Country of origin: Germany Product weight：0.55kg

HS code：8517623990

Inquire Now

Product Details：

Product Dimensions：

The P0916NG is a specialized Fieldbus Communications Module (FCM242 type) that provides a connection between the high-speed HDLC Fieldbus and the 2 Mbps Fieldbus. Its primary role is to manage the flow of data from various DIN rail-mounted Input/Output (FBM) modules back to the control processor. It is designed for mounting on a standard baseplate and features a compact, ruggedized design suitable for industrial environments. The module provides galvanic isolation and ensures deterministic communication, which is a requirement for real-time process control.

Product Parameters

Module Type: Fieldbus Communications Module (FCM242 equivalent)
Part Number: P0916NG
Communication Speed: Supports 2 Mbps Fieldbus and HDLC Fieldbus protocols
Power Requirements: Typically consumes $2 \text{ W}$ to $3 \text{ W}$ at $24 \text{ VDC}$ from the baseplate
Operating Temperature: $0\text{°C}$ to $60\text{°C}$ ( $32\text{°F}$ to $140\text{°F}$ )
Relative Humidity: 5% to 95% (non-condensing)
Isolation: Up to $600 \text{ VAC}$ between fieldbus and ground
Diagnostic Indicators: Front-panel LEDs for module status, communication activity, and fault detection
Form Factor: DIN rail baseplate mounted

Product Advantages

One of the key advantages of the P0916NG is its High Reliability and Redundancy Support. It is frequently used in redundant pairs, where if one module fails, the secondary module takes over communication instantly without bumping the process. The High-Speed Deterministic Performance ensures that process variables are updated at precise intervals, which is critical for stable control loops.

Additionally, the Modular Hardware Design allows for "Hot Swapping," meaning the module can be removed or replaced while the system remains powered and operational, significantly reducing maintenance downtime. The Galvanic Isolation integrated into the module protects the control processor from electrical surges or ground loops originating in the field, enhancing overall system longevity.

Important Considerations and Precautions

When installing the P0916NG, it is essential to ensure that the Baseplate Addressing is correctly set before the module is powered up; incorrect addressing can cause communication conflicts within the DCS. Because the module is a Sensitive Electronic Device, technicians must use grounded wrist straps to prevent electrostatic discharge (ESD) during handling.

Another critical precaution is to check the Fieldbus Termination. If the Fieldbus is not properly terminated at both ends, signal reflections can occur, leading to intermittent communication errors that are difficult to diagnose. Furthermore, while the module supports hot-swapping, it is a best practice to verify that the Control Processor recognizes the redundant partner as "Healthy" before removing a live module for maintenance. Lastly, ensure the Ambient Environment stays within the rated temperature range, as excessive heat can lead to premature aging of the internal capacitors.

Product Applications

The Foxboro P0916NG is a core component in large-scale industrial automation where the Foxboro I/A Series or EcoStruxure DCS is deployed.

Petrochemical Refining: Managing the high-speed data flow for distillation columns, reactors, and blending units where precision timing is required.
Power Generation: Interfacing with boiler and turbine control systems that demand 100% availability and fast response times.
Chemical Processing: Handling the I/O communication for batch processes that involve complex interlocking and sequencing.
Water and Wastewater: Serving as a communication hub in distributed pump stations and treatment plants.
Pulp and Paper: Coordinating the various stages of the paper machine and pulping process where a high volume of I/O points must be monitored.

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
